Figure 60 shows the cables that are required to connect the serial port of a SmartNode 2300 to a standard X.21
or V.35 network termination unit (NTU).
S LO
T
3
S LO
T
2
S LO
T
1
SmartNode
2300
SmartNode
2300
Connecting cables
DB-25, male
TXDa 12
TXDb 11
RXDa 9
RXDb 10
SETa 22
SETb 21
INDa 23
INDb 16
CNTa 14
CNTb 13
RTSa 8
CTSb 25
SIGNAL GROUND 7
DTR 6
DCD 4
DB-25, male
TXDa 12
TXDb 11
RXDa 9
RXDb 10
RXCa 22
RXCb 21
TXCa 23
TXCb 16
RTS 8
DTR 6
DCD 4
CTS 25
SIGNAL GROUND 7
FRAME GROUND 1
Figure 60. V.35 and X.21 modem connection
6 • SmartNode 2300 installation
X.21
2 TXDa
9
4
11
6
13
5
12
3
10
8
V.35
P
S
R
T
V
X
Y
a
C
H
F
D
B
A
Leased-line modem
Modem
NTU
Modem
NTU
