SmartNode 1000 and 2000 Series Getting Started Guide
Physical description
SN1200
•
Chassis dimensions: 1.6H x 8.7W x 6.3D in. (40H x 220W x 160D mm)
•
Weight: 21.2 oz (600 g)
•
CPU Motorola MPC850 at 50 MHz
•
Memory 16 Mb SDRAM
•
Flash memory 4 Mb
•
2-channel DSP
•
Power dissipation 4 W
•
Power supply AC 100–240 VAC, 50–60 Hz, 70 mA
SN1400
•
Chassis dimensions: 1.6H x 8.7W x 6.3D in. (40H x 220W x 160D mm)
•
Weight: 21.2 oz (600 g)
•
CPU Motorola MPC850 at 50 MHz
•
Memory 16 Mb SDRAM
•
Flash 4 Mb
•
4-channel DSP
•
Power dissipation 4 W
•
Power supply AC 100–240 VAC, 50–60 Hz, 70 mA
SN2300
•
Chassis dimensions: 1.7H x 17.3W x 10.4D in. (42H x 440W x 265D mm)
•
Weight 58.2 oz (1650 g)
•
CPU Motorola MPC860 at 50 MHz
•
Memory 16 Mb SDRAM
•
Flash 4 Mb
•
Power dissipation 30 W, fully loaded interface card (IC) slots, without internal 48V (or 40V) Line Power
Module PM-48V-INT (or PM-40V-INT)
•
Power supply AC 100–240 V, 50–60 Hz, max. 400 mA
SN2400
•
Chassis dimensions: 1.7H x 17.3W x 10.4D in. (42H x 440W x 265D mm)
•
Weight 58.2 oz (1650 g)
•
CPU Motorola MPC750 at 333 MHz
Physical description
B • Specifications
140
