SmartNode 1000 and 2000 Series Getting Started Guide
S LO
T
4
S LO
T
3
S LO
T 2
S LO
T
1
RJ-45, male
Rx+
Tx-
Tx-
Rx-

Installing the interface card cables

The following interface cards are available for use with the SmartNode 2400:
• IC-4FXS—Gateway interface card for 4 analog FXS ports (see section
card cables")
Note
• IC-4BRV-8V—8-channel gateway interface card for ISDN BRI (see section
interface card cables"
Note
• IC-E1V—30-channel E1 gateway interface card for ISDN PRI (see section
card cables" on page 108)
• IC-T1V—23-channel T1 gateway interface card for ISDN PRI (see section
face card cables" on page 109)
Determine which cards are installed in your SmartNode 2400, then go to the appropriate section to install
the device.
Connecting cables
3
4
5
6
Figure 71. Connecting to a hub
IC-4FXS is not supported in the Model SN2400/48 DC-
powered unit
on page 107)
When installed in a SmartNode Model SN2400/48, the IC-4BRV-
8V interface card does not operate with the 40V line power module
and it only supports the following:
• ISDN telephone handsets that have built-in power supplies
•
ISDN telephones powered from an S-Bus power supply
7 • SmartNode 2400 installation
Straight-through cable
"Installing the IC-4FXS interface
Hub
RJ-45, male
3
4
5
6
"Installing the IC-4BRV-8V
"Installing the IC-E1V interface
"Installing the IC-T1V inter-
105
