Patton electronics Patton SmartNode 2300 Series Specification Sheet

Patton's SmartNode 2300 Modular VoIP Access Router creates a flexible enterprise solution
for easy integration of voice and data. Scalable, intelligent, and multi-service, the SmartNode 2300 supports up
to 60 simultaneous calls and is equipped with a Sync. Serial router with QoS, NAT, and Firewall.
Modular VoIP Access Router
Patton SmartNode 2300
T
he SmartNode 2300 Modular VoIP Access Router is a single flexible
platform for network data and Voice-over-IP applications. Ideal for
the branch office or the small to medium enterprise, the SmartNode
2300 is performance-tuned for packet and voice. Equipped with
dual Ethernet ports, a serial V.35/X.21 port, and three voice interface slots, the
SmartNode 2300 scales up to 60 simultaneous calls in a 1U chassis.
The SmartNode 2300 connects your LAN to the WAN using PPP or Frame
Relay (RFC-1490) eliminating the need for and cost of an extra router. With dual
Ethernet ports and built-in QoS, NAT, DHCP, PPPoE, and ACL/Firewall, the
SmartNode 2300 provides complete LAN network access control.
With Patton's Telephony-over-IP (ToIP) programmable circuit-switching the
SmartNode links any standard BRI, T1/E1 PRI, or FXS connection to the IP
network. Supporting multiple codecs and T.38/Modem bypass, the SmartNode
seamlessly converges voice, data, and fax over IP.
The SmartNode delivers IP network access with the clarity of toll-quality voice
for a complete LAN, WAN, and Gateway solution. For more information, visit
us at www.patton.com.
SMARTNODE 2300 SERIES
Up to 60 Simultaneous Calls
Supports up to 60 simultaenous calls from any combination
of voice intefaces including T1/E1 PRI, BRI, and FXS.
Compatible CODECs
Connect to any gateway with any one of our standard codecs
(including G.711 and G.726). For low bandwidth require-
ments, use G.723.1 and G.729ab vocoders.
Complete Service Transparency
Using ISoIP™ and ToIP™ technology, calls are connected
with voice, data, and supplementary services delivered
transparently end-to-end.
T1/E1, BRI, & FXS Voice Interface Cards
Use any combination of voice interfaces for connection to
any telephone, switch, or service provider. Scale your con-
nections by simply adding new interfaces.
H.323v3 and H.323+ VoIP
Connect to any SmartNode or VoIP capable device with universal
call control signalling. Use advanced features including H.245
Fast Connect, Early Start, Annex M3, ECS support, and RAS.
V.35/X.21 Router with Dual Ethernet
Connect your LAN to any broadband access network with its
built-in sync. serial router. Use NAT, DHCP, and ACLs while
guaranteeing voice priority and service quality.
VoIP—ToIP
