Operating modes

The four ports can be used in three different modes, which are tabulated in
• An X in the NET column of the table means that the port performs network side signaling and that the pin
out corresponds to an ISDN NT. A NET port is connected to an ISDN terminal, i.e. a telephone or a PBX.
• An X in the USR column means that the port performs user side signaling and the pin out corresponds to
an ISDN terminal. The two ports (2, 3) have configurable pin outs.
• An X in the HW Bypass column refers to the fallback mode.
The possible BRI port configurations are listed in

Hardware bypass

BRI 1 and BRI 2 can be used to provide an emergency service. If a power failure occurs a relay connects these
two interfaces with each other.
• BRI 1 must be connected with a telephone terminal or PBX if the bypass is active.
• BRI 2 must be connected to the ISDN network if the bypass is active.
Interface cards descriptions
table
Table 14. BRI Port Configurations
Port NET
BRI 0 X
BRI 1 X
BRI 2 X
BRI 3 X
table
14.
USR HW Bypass
X
X
