Chapter 9 Configuring IP Routing

Configuring Route Calculation Timers

You can configure the delay time between when OSPF receives a topology change and when it starts an
SPF calculation. You also can configure the hold time between two consecutive SPF calculations.
To configure route calculation timers, perform the following steps:
Step 1 If you have not already done so, enter the router configuration mode for the OSPF process you want to
configure by entering the following command:
hostname(config)# router ospf process_id
Step 2 To configure the route calculation time, enter the following command:
hostname(config-router)# timers spf spf-delay spf-holdtime
The spf-delay is the delay time (in seconds) between when OSPF receives a topology change and when
it starts an SPF calculation. It can be an integer from 0 to 65535. The default time is 5 seconds. A value
of 0 means that there is no delay; that is, the SPF calculation is started immediately.
The spf-holdtime is the minimum time (in seconds) between two consecutive SPF calculations. It can be
an integer from 0 to 65535. The default time is 10 seconds. A value of 0 means that there is no delay;
that is, two SPF calculations can be done, one immediately after the other.
The following example shows how to configure route calculation timers:
hostname(config)# router ospf 1
hostname(config-router)# timers spf 10 120

Logging Neighbors Going Up or Down

By default, the system sends a system message when an OSPF neighbor goes up or down.
Configure this command if you want to know about OSPF neighbors going up or down without turning
on the debug ospf adjacency command. The log-adj-changes router configuration command provides
a higher level view of the peer relationship with less output. Configure log-adj-changes detail if you
want to see messages for each state change.
To log neighbors going up or down, perform the following steps:
If you have not already done so, enter the router configuration mode for the OSPF process you want to
Step 1
configure by entering the following command:
hostname(config)# router ospf process_id
To configure logging for neighbors going up or down, enter the following command:
Step 2
hostname(config-router)# log-adj-changes [detail]
Note
The following example shows how to log neighbors up/down messages:
OL-12172-03
Logging must be enabled for the the neighbor up/down messages to be sent.
Cisco Security Appliance Command Line Configuration Guide
Configuring OSPF
9-17
