The Main Bat field displays the voltage of the AB1G battery.
The following table shows how to interpret the voltage levels.
Main
Battery Status
High
High
Medium
Low
Critically low
The Main Batt Flag field displays the battery status, which is
linked to the battery icon described on page 7. You can continue
using the battery until the CK31 indicates that the battery is
low: the battery light turns on and the low battery icon (
appears on the taskbar.
The Supercap field displays the voltage of the backup battery.
The main battery continually charges the backup battery unless
the main battery is critically low or removed.
Backup
Battery
Status
High
High
Low
Low
There are some usage patterns that can deplete the backup
battery. For example, if you remove the main battery every night
to charge it outside the CK31, the backup battery will be low in
the morning. This usage pattern does not harm the backup
battery.
When the backup battery is low, the Backup Battery Very Low
dialog box appears on your CK31 screen.
CK31 Handheld Computer User's Manual
Chapter 4 — Running Diagnostics
Main Battery Voltage
8500 mV
> 8000 mV
7600 to 7999 mV
7200 to 7599 mV
< 7199 mV
Backup Battery
Voltage Condition
> 2400 mV Fully charged
> 2200 mV OK to swap the main battery
> 1750 mV OK to swap the main battery if
you first suspend the CK31
< 1750 mV Do not swap the main battery
because the CK31 might cold
boot
Percentage
of Battery
100%
> 75%
50% to 75%
25% to 50%
< 25%
)
97
