The SC-222W multi-band plastic antenna is an omni-directional interior antenna that
gathers signals from all sides. Range of antenna is dependent on three factor:
1) physical obstructions, 2) power generated by booster and 3) reception from outside
signal received and distributed by outside antenna.
Besides the antenna itself, parts include
mounting equipment for either a flat horizontal
surface or a wall. It should be mounted in
an upright position for best results.
Step 1: Drill a 35mm diameter hole in the ceiling. The ceiling
thickness should be 20mm, maximum.
Step 2: Unscrew fixing nut from antenna. Place antenna cable
through hole. Screw the fixing nut back onto antenna
and cable on crawl space side of ceiling and fasten.
Step 3: Attach the N-Female connection from the interior antenna to the cable leading to
the connector labeled INSIDE, on your booster.
Step 4: Tighten fixing nut to secure antenna (do not over-tighten).
• Storage and transportation: Store and place in non-extreme room-temperature and
dry environment
• Attention: This antenna should not be used near open fire or flame
