Epson Perfection V700 Photo Service Manual page 34

EPSON Perfection V700 Photo
Step Possible Cause
The DRV-SUB_B FFC is not connected to Connector CN1 on the
1
SUB_B Board and Connector CN4 on the DRV Board.
2 Connector CN2 and CN4 on the SUB_B Board are not connected.
3 Failure of the SUB_C Board and the SUB_D Board
4 DRV Board failure
5 Main Board failure
Step Possible Cause
1 The host computer does not support USB 2.0 or IEEE 1394.
The TWAIN Driver supplied with the scanner has not been installed
2
correctly.
3 The USB 2.0 or IEEE 1394 cables are damaged.
4 Main Board failure
Note : USB 2.0 may be installed but disabled on the host computer. Check the
Troubleshooting
Table 3-11. The TPU LEDs Do Not Light Up
Corrective Action
Connect the DRV-SUB_B FFC to CN1 on the SUB_B Board and
CN4 on the DRV Board.
Connect CN2 and CN4.
Replace the SUB_C Board and the SUB_D Board.
Replace the DRV Board.
Replace the Main Board.
Table 3-12. Interface Error
Corrective Action
Replace or modify the host computer.
Install (reinstall) the TWAIN Driver for the Perfection V700 Photo.
Replace the USB 2.0 or IEEE 1394 cables.
Replace the Main Board.
under Windows.
Device Manager
Troubleshooting
Revision A
Reference
See Section 4.2.10 on page 56. (Figure 4-40)
See Section 4.2.14 on page 61. (Figure 4-53)
See Section 4.2.12 on page 58. (Figure 4-46)
See Section 4.2.13 on page 59.
See Section 4.2.14 on page 61.
See Section 4.2.5 on page 45.
Reference
-
-
-
See Section 4.2.5 on page 45.
34
