EPSON Perfection V700 Photo
Step Possible Cause
1 The Document Glass is not clean. (Image has white spots)
2 ISN Board failure
3 Main Board failure
Step Possible Cause
1 A connector is disconnected.
2 CR Motor failure
Step Possible Cause
1 The Carriage Lock has not been released.
2 The Upper Housing is not installed correctly.
Carriage Mechanism failure
• The CR Motor does not operate normally when powered-on with
3 the Upper Housing removed.
• The Carriage Unit does not move normally with the CR Motor
removed.
4 CR Motor failure
Step Possible Cause
1 Main Board failure
Troubleshooting
Table 3-4. Scanned Image Quality Error
Clean the glass.
Replace the Carriage Unit.
Replace the Main Board
Table 3-5. The Main Unit Does Not Operate When Powered-On
Connect the disconnected connectors.
Replace the CR Motor.
Replace the Main Board.
Table 3-6. The Carriage Unit Does Not Operate
Release the Carriage Lock.
Install it normally.
Replace the Carriage Unit.
Replace the CR Motor.
Replace the Main Board.
Table 3-7. The Carriage Unit Operates, Scanner Indicates Error
Replace the Main Board.
Troubleshooting
Corrective Action
Corrective Action
Corrective Action
Corrective Action
Revision A
Reference
See Chapter 6
See Section 4.2.6 on page 48.
See Section 4.2.5 on page 45.
Reference
See Section 7.1.2 on page 73.
See Chapter 4
See Section 4.2.7 on page 50.
See Section 4.2.5 on page 45.
Reference
See Step 3 of Section 4.2.2 on page 40.
See Section 4.2.2 on page 40.
See Section 4.2.6 on page 48.
See Section 4.2.7 on page 50.
See Section 4.2.5 on page 45.
Reference
See Section 4.2.5 on page 45.
