Access Rule
When you finish the settings, simply click OK to save the configuration.
3 . 7 . 3 D i s k S t a
3 . 7 . 3 D i s k S t a
This page can display current using status of the USB diskette. If you want to remove the
diskette from USB port in router, please check the box of Safely Remove Disk first. And then,
remove the USB diskette later.
Safely Remove Disk
Manufacturer
Model
Size
Free Capacity
Status
Update
3 . 7 . 4 D i s k S h
3 . 7 . 4 D i s k S h
This page can define the folder which will be shared while Samba File Sharing is enabled.
To add a new entry for disk sharing, please click Add a New Entry to open the following
page.
Vigor2130 Series User's Guide
Note: When write protect status for the USB diskette is
ON, you cannot type any new folder name in this field.
Only "/" can be used in such case.
Select the access right for the USB diskette.
t u s
t u s
Check this box and then you can remove the USB diskette
safely.
Display the manufacturer of the disk.
Display the type of the disk.
Display the storage space of the diskette(s).
Display the free disk space of the diskette(s).
Display current usage status of the diskette(s)
Click this button to refresh the disk status.
a r e s
a r e s
