Page 2 Vigor2130 Series High Speed Gigabit Router User’s Guide Version: 1.1 Date: 25/11/2009 Vigor2130 Series User’s Guide...
Page 3 Web registration is preferred. You can register your Vigor router via Owner http://www.draytek.com. Firmware & Tools Due to the continuous evolution of DrayTek technology, all routers will be regularly Updates upgraded. Please consult the DrayTek web site for more information on newest firmware, tools and documents.
Page 4: Regulatory Information
Product: Vigor2130 Series Router DrayTek Corp. declares that Vigor2130 Series of routers are in compliance with the following essential requirements and other relevant provisions of R&TTE Directive 1999/5/EEC. The product conforms to the requirements of Electro-Magnetic Compatibility (EMC) Directive 2004/108/EC by complying with the requirements set forth in EN55022/Class B and EN55024/Class B.
Page 5: Table Of Contents
3.2.2 Ports..........................44 3.2.3 MAC Address Table......................45 3.2.4 VLAN..........................47 3.2.5 Monitor Port ........................48 3.2.6 Static Route ........................48 3.2.7 Bind IP to MAC ....................... 50 3.3 NAT ............................52 3.3.1 Hardware NAT ........................ 52 Vigor2130 Series User’s Guide...
Page 6 3.9.4 Syslog / Mail Alert ......................99 3.9.5 Time and Date ......................101 3.9.6 Management......................... 102 3.9.7 Reboot System ......................102 3.9.8 Firmware Upgrade ......................103 Admin Mode Operation..................105 4.1 WAN ............................ 105 4.1.1 Internet Access ......................107 4.1.2 Ports..........................113 Vigor2130 Series User’s Guide...
Page 7 4.9.1 USB General Settings....................177 4.9.2 FTP User Management ....................178 4.9.3 Disk Status........................179 4.9.4 Disk Shares ........................179 4.10 IPv6 ........................... 181 4.10.1 IPv6 WAN Setup......................181 4.10.2 IPv6 LAN Setup ......................185 4.10.3 IPv6 Firewall Setup..................... 186 Vigor2130 Series User’s Guide...
Page 8 5.4 Checking If the ISP Settings are OK or Not ................ 219 5.5 Forcing Vigor Router into TFTP Mode for Performing the Firmware Upgrade ....221 5.6 Backing to Factory Default Setting If Necessary ..............224 5.7 Contacting Your Dealer ....................... 225 Vigor2130 Series User’s Guide viii...
Page 9: Preface
The Vigor2130 series are the routers with high speed in data transmission through WAN port and LAN ports. With hardware NAT acceleration, the rate of Vigor2130 series can be greater than 900Mbps almost. With the development of NGN (Next Generation Network), you may recently hear the news about FTTx deployment in your local area or even have already subscribed the unbundling last mile service (e.g.
Page 10: Led Indicators And Connectors
The DoS/DDoS function is active. Blinking It will blink while detecting an attack. Interface Description Connector for accessing the Internet. LAN (1-4) Connectors for local networked devices. Connector for USB storage device (Pen Driver/Mobile HD) or printer or 3G backup. Vigor2130 Series User’s Guide...
Page 11 5 seconds. When you see the ACT LED begins to blink rapidly than usual, release the button. Then the router will restart with the factory default configuration. Connector for a power adapter. Power Switch. ON/OFF Vigor2130 Series User’s Guide...
Page 12: For Vigor2130N
Press the button once to enable (WLAN LED on) or WLAN disable (WLAN LED off) wireless connection. Connector for accessing the Internet. LAN (1-4) Connectors for local networked devices. Connector for USB storage (Pen Driver /Mobile HD) or printer. Vigor2130 Series User’s Guide...
Page 13 5 seconds. When you see the ACT LED begins to blink rapidly than usual, release the button. Then the router will restart with the factory default configuration. Connector for a power adapter. Power Switch. ON/OFF Vigor2130 Series User’s Guide...
Page 14: For Vigor2130Vn
Press the button once to enable (WLAN LED on) or WLAN disable (WLAN LED off) wireless connection. Connector for accessing the Internet. LAN (1-4) Connectors for local networked devices. Connector for USB storage (Pen Driver/Mobile HD) or printer. Vigor2130 Series User’s Guide...
Page 15 5 seconds. When you see the ACT LED begins to blink rapidly than usual, release the button. Then the router will restart with the factory default configuration. Connector for a power adapter. Power Switch. ON/OFF Vigor2130 Series User’s Guide...
Page 16: Hardware Installation
4 PCs directly. Connect Phone port to a conventional analog telephone. Connect detachable antennas to the router for Vigor2130 series (n model). Connect one end of the power cord to the power port of this device. Connect the other end to the wall outlet of electricity.
Page 17: Stand Installation
The Vigor2130 must be placed erectly. Therefore you have to install a stand onto the router to make it standing firmly. Please follow the figures listed below to finish the installation. Vigor2130 Series User’s Guide...
Page 18: Printer Installation
You can install a printer onto the router for sharing printing. All the PCs connected this router can print documents via the router. The example provided here is made based on Windows XP/2000. For Windows 98/SE/Vista, please visit www.draytek.com. Before using it, please follow the steps below to configure settings for connected computers (or wireless clients).
Page 19 Click Local printer attached to this computer and click Next. In this dialog, choose Create a new port Type of port and use the drop down list to select Standard TCP/IP Port. Click Next. Vigor2130 Series User’s Guide...
Page 20 In the following dialog, type 192.168.1.1 (router’s LAN IP) in the field of Printer Name or IP Address and type IP_192.168.1.1 as the port name. Then, click Next. Click Standard and choose Generic Network Card. Then, in the following dialog, click Finish. Vigor2130 Series User’s Guide...
Page 21 11. Select "LPR" on Protocol, type p1 (number 1) as Queue Name. Then click OK. Next please refer to the red rectangle for choosing the correct protocol and UPR name. Vigor2130 Series User’s Guide...
Page 22 If you do not know whether your printer is supported or not, please visit www.draytek.com to find out the printer list. Open Support >FAQ; find out the link of Printer Server and click it; then click the What types of printers are compatible with Vigor router? link.
Page 23: Configuring Basic Settings
The web page can be logged out according to the chosen condition. The default setting is Auto Logout, which means the web configuration system will logout after 5 minutes without any operation. Change the setting for your necessity. Vigor2130 Series User’s Guide...
Page 24: Changing Password
Now, the Main Screen will appear. Main screen for admin mode operation (full configuration) Main screen for user mode operation (simple configuration) Note: The home page will change slightly in accordance with the type of the router you have. Vigor2130 Series User’s Guide...
Page 25 Type New Password in New Password and Confirm New Password fields. Then click OK to continue. Now, the password has been changed. Next time, use the new password to access the Web Configurator for this router. Vigor2130 Series User’s Guide...
Page 26: Quick Start Wizard
The first screen of Quick Start Wizard is welcome page, please click Next. The first screen of Quick Start Wizard is entering login password. After typing the password, please click Next. Vigor2130 Series User’s Guide...
Page 27: Setting Up The Time Zone
On the next page as shown below, please select the appropriate connection type according to the information from your ISP. There are five types offered in this page. Each connection type will bring out different web page. Vigor2130 Series User’s Guide...
Page 28 Clone MAC Address It is available when the box of Enable is checked. Click Clone PC Address. The result will be displayed in the field of MAC Address. After finishing the settings here, please click Next. Vigor2130 Series User’s Guide...
Page 29 Ethernet can share a common connection. PPPoE is used for most of DSL modem users. All local users can share one PPPoE connection for accessing the Internet. Your service provider will provide you information about user name, password, and authentication mode. Vigor2130 Series User’s Guide...
Page 30 Clone MAC Address It is available when the box of Enable is checked. Click Clone PC Address. The result will be displayed in the field of MAC Address. After finishing the settings here, please click Next. Vigor2130 Series User’s Guide...
Page 31 XX ~ XX. It means Max Transmit Unit for packet. The default MTU Size setting is 1442. Enable The router will detect the MAC address automatically. Or, check the box to enable MAC address cloning. Vigor2130 Series User’s Guide...
Page 32: Setting Up The Wireless Connection
It means the identification of the wireless LAN. SSID can be any text numbers or various special characters. The default SSID is "DrayTek". We suggest you to change it. Wireless Mode Choose the wireless mode for this router. At present, only 802.11B/B/N mix is available.
Page 33 Four keys can be entered here, but only one key can be selected at a time. The keys can be entered in ASCII or Hexadecimal. Choose the key you wish to use by using the Default Key drop down list. Vigor2130 Series User’s Guide...
Page 34 Select WPA, WPA2 or Auto as WPA mode. WPA Algorithm Choose the WPA algorithm, TKIP, AES or Auto. WPA Pre-shared Key The keys can be entered in ASCII or Hexadecimal. Check the key you wish to use. Vigor2130 Series User’s Guide...
Page 35 Choose the WPA algorithm, TKIP, AES or Auto. Server IP Address Enter the IP address of RADIUS server. Destination Port The UDP port number that the RADIUS server is using. The default value is 1812, based on RFC 2138. Vigor2130 Series User’s Guide...
Page 36 Start PIN button. The WLAN LED on the router will blink fast when WPS is in progress. It will return to normal condition after two minutes. (You need to setup WPS within two minutes) After finishing the settings here, please click Next. Vigor2130 Series User’s Guide...
Page 37: Saving The Wizard Configuration
Displays the IP address of the LAN interface. TX Packets Displays the total transmitted packets at the LAN interface. RX Packets Displays the total number of received packets at the LAN interface. WAN Status Line Displays the physical connection (Ethernet) of this interface. Vigor2130 Series User’s Guide...
Page 38: Saving Configuration
Each time you click OK on the web page for saving the configuration, you can find messages showing the system interaction with you. Ready indicates the system is ready for you to input settings. Settings Saved means your settings are saved once you click Finish or OK button. Vigor2130 Series User’s Guide...
Page 39: User Mode Operation
These are known as private IP addresses, and are listed in the following ranges: From 10.0.0.0 to 10.255.255.255 From 172.16.0.0 to 172.31.255.255 From 192.168.0.0 to 192.168.255.255 Vigor2130 Series User’s Guide...
Page 40 Besides, 3G USB Modem also can be used as backup device. Therefore, when WAN is not available, the router will use 3.5G for supporting automatically. The supported 3G USB Modem will be listed on DrayTek web site. Please visit www.draytek.com for more detailed information.
Page 41: Internet Access
To use Static as the accessing protocol of the internet, please choose Static mode from Connection Type drop down menu. The following web page will be shown. IP Address Type the IP address. Subnet Mask Type the subnet mask. Vigor2130 Series User’s Guide...
Page 42 It is available when the box of Enable is checked. Click Clone MAC Address. The result will be displayed in the field of MAC Address. After finishing all the settings here, please click OK to activate them. Vigor2130 Series User’s Guide...
Page 43 To choose PPPoE as the accessing protocol of the internet, please select PPPoE from the Internet Access menu. The following web page will be shown. Username Type in the username provided by ISP in this field. Vigor2130 Series User’s Guide...
Page 44 It is available when the box of Enable is checked. Click Clone MAC Address. The result will be displayed in the field of MAC Address. After finishing all the settings here, please click OK to activate them. Vigor2130 Series User’s Guide...
Page 45 If you choose Static IP for WAN IP Network Settings, you can specify secondary DNS server IP address here because your ISP often provides you more than one DNS Server. If your ISP does not provide it, the router will apply a default secondary DNS Server automatically. Vigor2130 Series User’s Guide...
Page 46 Such value is used to initialize USB modem. Please use the default value. If you have any question, please contact to your ISP. APN means Access Point Name which is provided and APN Name required by some ISPs. Vigor2130 Series User’s Guide...
Page 47: Ports
It can set the speed and duplex of the port. You can use the drop down list to choose the required speed for the router. If you have no idea in configuring speed, simple use the default setting, Auto. Vigor2130 Series User’s Guide...
Page 48: Backup
WAN connection type is not in 3G mode. When the WAN connection is broken, router will try to keep the connection with 3G mode. After WAN connection is recovered, router will disconnect the 3G connection automatically. Vigor2130 Series User’s Guide...
Page 49: Lan
IP address to private IP address to forward the right packets to the right host and vice versa. Besides, Vigor router has a built-in DHCP server that assigns private IP address to each local host. See the following diagram for a briefly understanding. Vigor2130 Series User’s Guide...
Page 50 Vigor router will exchange routing information with neighboring routers using the RIP to accomplish IP routing. This allows users to change the information of the router such as IP address and the routers will automatically inform for each other. Vigor2130 Series User’s Guide...
Page 51: General Setup
This page provides you the general settings for LAN. Click LAN to open the LAN settings page and choose General Setup. IP Address Type in private IP address for connecting to a local private network (Default: 192.168.1.1). Vigor2130 Series User’s Guide...
Page 52: Ports
It can set the speed and duplex of the port. You can use the drop down list to choose the required speed for the router. If you have no idea in configuring speed, simple use the default setting, Vigor2130 Series User’s Guide...
Page 53: Mac Address Table
PerfectReach: Link up power savings enabled. Enabled: Both link up and link down power savings enabled. Refresh Click this button to refresh the information for LAN ports. After finishing all the settings here, please click OK to activate them. Vigor2130 Series User’s Guide...
Page 54 To add a new static MAC entry, click Add new static entry. A new entry will be shown as follows. Choose VLAN ID and type a new MAC address. Next, specify port member for this table. Finally, click OK to save the changes. Vigor2130 Series User’s Guide...
Page 55: Vlan
To add or remove a VLAN, please refer to the following example. VLAN 1 is consisted of hosts linked to P1 ~ P4. After checking the box to enable VLAN function, you will check the table according to the needs as shown below. Vigor2130 Series User’s Guide...
Page 56: Monitor Port
Monitor egress port Check to set up the port(s) for being monitored. It only monitors the packets transmitted by the port you set up. Go to LAN to open setting page and choose Static Route. Vigor2130 Series User’s Guide...
Page 57 Main Router. Click the LAN - Static Route and click Add. Check the Enable box. Please add a static route as shown below, which regulates all packets destined to 192.168.10.0 will be forwarded to 192.168.1.2. Click OK. Vigor2130 Series User’s Guide...
Page 58: Bind Ip To Mac
When this function is enabled, all the assigned IP and MAC address binding together cannot be changed. If you modified the binding IP or MAC address, it might cause you not access into the Internet. Click LAN and click Bind IP to MAC to open the setup page. Vigor2130 Series User’s Guide...
Page 59 It allows you to add the one you choose from the ARP table or the IP/MAC address typed in Add and Edit to the table of IP Bind List. Edit It allows you to edit and modify the selected IP address and MAC address that you create before. Vigor2130 Series User’s Guide...
Page 60: Nat
Below shows the menu items for NAT. Hardware-base Acceleration Engine, also named Protocol Processing Engine API is the function that Draytek provides to extremely speed up the NAT performance. While the hardware acceleration mechanism is activated, most of the bandwidth usage will be concentrated on the specific sessions which increase transmission speed to get ultimately accelerated.
Page 61: Open Ports
Specify the starting port number of the service offered by the local host. End Port (optional) Specify the ending port number of the service offered by the local host. Local Host Enter the private IP address of the local host. Vigor2130 Series User’s Guide...
Page 62: Dmz Host
Click DMZ Host to open the following page: Enable Check to enable the DMZ Host function. DMZ IP Enter the private IP address of the DMZ host, or click Choose PC to select one. Vigor2130 Series User’s Guide...
Page 63: Bandwidth Management
Defines the default session number used for each computer in LAN. Limitation List Displays a list of specific limitations that you set on this web page. Start IP Defines the start LAN IP address for limit session. Vigor2130 Series User’s Guide...
Page 64: Bandwidth Limit
Click this button to close the function of limit bandwidth. Default TX limit Define the default speed of the upstream for each computer in LAN. Default RX limit Define the default speed of the downstream for each computer in LAN. Vigor2130 Series User’s Guide...
Page 65: Port Rate Control
Determine the unit (kbps/Mbps) for policer. Shaper Enabled Check this box to enable shaper function. Shaper Rate (Tx) Type the number for shaper function. The default value is 500. It is restricted to 500-1000000 when the Shaper Unit is set in Vigor2130 Series User’s Guide...
Page 66: Qos Control List
The core routers in the backbone will do the same checking before executing treatments in order to ensure service-level consistency throughout the whole QoS-enabled network. Vigor2130 Series User’s Guide...
Page 67 Display the value specified for the QCE. Traffic Class Display the class of the data transmission for the QCE. QoS Control List allows users to set up to five groups of QCL. Each QCL group can contain 12 QCE settings. Vigor2130 Series User’s Guide...
Page 68 If you choose VLAN ID as QCE Type, you have to type the ID number for it and specify traffic class from Low, Normal, Medium and High. If you choose TCP/UDP Port as QCE Type, you have to type the port number for it and specify traffic class from Low, Normal, Medium and High. Vigor2130 Series User’s Guide...
Page 69 If you choose ToS as QCE Type, you have to specify priority class from Low, Normal, Medium and High. If you choose Tag Priority as QCE Type, you have to specify priority class from Low, Normal, Medium and High. Vigor2130 Series User’s Guide...
Page 70: Ports Priority
ID, UDP/TCP port, IPv4/IPv6 DSCP or Tag Priority. Frames not matching any of the QCEs are classified to the default QoS class for the port. Port Indicate the interface for the physical port, WAN port, LAN port and Wireless Port. Vigor2130 Series User’s Guide...
Page 71: Qos Statistics
Use the drop down list to choose 1, 2, 4, or 8 as the queue weighted number. This page displays statistics for QoS setting. Click WAN/LAN link to check detailed information for each interface. Click WAN/LAN link to check detailed information for each interface. Vigor2130 Series User’s Guide...
Page 72 Display the number of 512 ~ 1023-byte frames in good and bad packets received. RX 1024- 1526 Bytes Display the number of 1024-1522-byte frames in good and bad packets received. RX 1527 Bytes Display the number of 1527-byte frames in good and bad packets received. Vigor2130 Series User’s Guide...
Page 73 Display the number of 1527-byte frames in good and bad packets transmitted. Tx Low Display the low queue counter of the packet transmitted. Tx Normal Display the normal queue counter of the packet transmitted. Tx Medium Display the medium queue counter of the packet received. Vigor2130 Series User’s Guide...
Page 74: Applications
Check this box to enable the current account. DynDNS Service Select the service provider for the DDNS account. Hostname Type in one domain name that you applied previously. Use the drop down list to choose the desired domain. Vigor2130 Series User’s Guide...
Page 75: Schedule
Check to enable the schedule. Start Date Specify the starting date of the schedule. Start Time Specify the starting time of the schedule. Action Specify which action should be applied during the period of the schedule. Vigor2130 Series User’s Guide...
Page 76: Igmp Snooping
Snooping Enabled Check the box to enable this function. Unregistered IPMC… Check the box to enable unregistered IPMC traffic flooding. Fast Leave Check the box to Fast Leave on the LAN port. Vigor2130 Series User’s Guide...
Page 77: Igmp Status
Windows XP and the router provide the associated support for MSN Messenger to allow full use of the voice, video and messaging features. Enable UPNP Enable UPnP function. You have to type the download and upload speed. Vigor2130 Series User’s Guide...
Page 78 This is because these applications will block the accessing ability of some network ports. Security Considerations Activating the UPnP function on your network may incur some security threats. You should consider carefully these risks before activating the UPnP function. Vigor2130 Series User’s Guide...
Page 79: Wireless Lan
Point (AP) connecting to lots of wireless clients or Stations (STA). All the STAs will share the same Internet connection via Vigor wireless router. The General Settings will set up the information of this wireless network, including its SSID as identification, located channel etc. Vigor2130 Series User’s Guide...
Page 80: General Setup
Below shows the menu items for Wireless LAN. By clicking the General Setup, a new web page will appear so that you could configure the SSID and the wireless channel. Please refer to the following figure for more information. Vigor2130 Series User’s Guide...
Page 81 It means the identification of the wireless LAN. SSID can be any text numbers or various special characters. The default SSID is "DrayTek". We suggest you to change it. Wireless Mode Choose the wireless mode for this router. At present, only 802.11B/B/N mix is available.
Page 82 PSK (Pre-Shared Key) entered manually in this field below or automatically negotiated via 802.1x authentication. WPA Mode Select WPA, WPA2 or Auto as the type. Vigor2130 Series User’s Guide...
Page 83 WPS (Wi-Fi Protected Setup) provides easy procedure to make network connection between wireless station and wireless access point (vigor router) with the encryption of WPA and WPA2. Vigor2130 Series User’s Guide...
Page 84 Start PBC button or using PIN Code. On the side of Vigor 2130 series which served as an AP, press WPS button once on the front panel of the router or click Start PBC on web configuration interface. On the side Vigor2130 Series User’s Guide...
Page 85: Access Control
MAC addresses to control their access rights (deny or allow). Filter Type Choose the rule for the MAC addresses displayed in this page. Allow List – all the MAC address of wireless clients listed here are allowed to do wireless connection. Vigor2130 Series User’s Guide...
Page 86: Station List
Display the MAC Address for the connecting client. Connected Time Display the connection time for the connecting client. Auto-refresh Check this box to force the system refreshing the table automatically. Refresh Click this button to refresh current page. Vigor2130 Series User’s Guide...
Page 87: Access Point Discovery
Therefore, before connecting the USB diskette into the Vigor router, please make sure the memory format for the USB diskette is FAT16 or FAT32. It is recommended for you to use FAT32 for viewing the filename completely (FAT16 cannot support long filename). Vigor2130 Series User’s Guide...
Page 88: Ftp User Management
OK, the router will create the specific/new folder in the USB diskette. In addition, if the user types “/” here, he/she can access into all of the disk folders and files in USB diskette. Vigor2130 Series User’s Guide...
Page 89: Disk Status
Click this button to refresh the disk status. This page can define the folder which will be shared while Samba File Sharing is enabled. To add a new entry for disk sharing, please click Add a New Entry to open the following page. Vigor2130 Series User’s Guide...
Page 90 All Users Read-only - everyone has read-only access to the share disk. All Users Read-write - everyone has read-write access to the share disk. Specific Users – Only specific user(s) can access into the share disk. Vigor2130 Series User’s Guide...
Page 91: Ipv6
Link-Local address is used for communicating with neighbouring nodes on the same link. It is defined by the address prefix fe80::/10. You don't need to setup Link-Local address manually for it is generated automatically according to your MAC Address. Vigor2130 Series User’s Guide...
Page 92 Primary DNS Server Type your IPv6 primary DNS Server address here. Secondary DNS Server Type your IPv6 secondary DNS Server address here. DHCPv6 client type would use DHCPv6 Client protocol to obtain IPv6 address from server. Vigor2130 Series User’s Guide...
Page 93 After getting the IPv6 prefix and starting router advertisement daemon (RADVD), the PC behind this router can directly connect to IPv6 the Internet. Username Type the name obtained from the broker. “vigor2130” is a default username applied from Vigor2130 Series User’s Guide...
Page 94 If_prefix Display LAN interface name. interface that will be configured with the first 64 of the received prefix from the broker and the router advertisement daemon is started to advertise that prefix on the if_prefix interface. Vigor2130 Series User’s Guide...
Page 95: Ipv6 Lan Setup
One is RADVD(stateless) and the other is DHCPv6 Server (Stateful). DHCPv6 Server - DHCPv6 Server could assign IPv6 address to PC according to the Start/End IPv6 address configuration. IPv6 Start Address/IPv6 End Address- Type the start and end address for IPv6 server. Vigor2130 Series User’s Guide...
Page 96: Ipv6 Firewall Setup
Display the destination IP address of such rule. Source Port Display the source port number of such rule. Destination Port Display the destination port number of such rule. Action Display the status (accept or drop) of such rule. Vigor2130 Series User’s Guide...
Page 97 Type the subnet mask here if you choose Subnet as Source IP Type. Destination IP Type Determine the IP type as the destination. Destination IP Type the IP address here if you choose Single as Destination IP Type. Vigor2130 Series User’s Guide...
Page 98: Ipv6 Routing
Expires Display the lifetime of the route. he largest size (in bytes) of a packet. Display t he largest size (in bytes) of an unfragmented Advmss Display t piece of a routing advertisement. Vigor2130 Series User’s Guide...
Page 99: Ipv6 Neighbour
IPv6 TSPC status web page could help you to diagnose the connection status of TSPC. TSPC log contains some debug information from program. If TSPC has not configured properly, the router will display the following page when the user tries to connect through TSPC connection. Vigor2130 Series User’s Guide...
Page 100 Connecting - The remote client is connecting to the tunnel server. Connected – The remote client has been connected to the tunnel server. Activity Sent - sent to the tunnel (RX bytes). Received - received from the tunnel (RX bytes). Vigor2130 Series User’s Guide...
Page 101 Users can use such IP for connecting to IPv6 network. When your PC obtains the IPv6 address, please connect to http://www.ipv6.org. If your PC access Internet via IPv6 connection, your IPv6 address will be shown on the web page immediately. Refer to the following figure. Vigor2130 Series User’s Guide...
Page 102: User
Allow FTP Check this box to let the user connect to FTP server. When you finish the settings, simply click OK to save the configuration. The new user will be created and displayed on the page. Vigor2130 Series User’s Guide...
Page 103: System Maintenance
Below shows the menu items for System Maintenance. The System Status provides basic network settings of Vigor router. It includes LAN and WAN interface information. Also, you could get the current running firmware version or firmware related information from this presentation. Vigor2130 Series User’s Guide...
Page 104 Wireless LAN------- MAC Address Display the MAC address of the wireless LAN. Device Type Display the device type used for wireless LAN. SSID Display the SSID of the router. Channel Display the channel that wireless LAN used. Vigor2130 Series User’s Guide...
Page 105: User Password
Type a key arbitrarily for encrypting the file. Keep the key in mind. You will need it whenever you want to restore such file. Click Backup button to get into the following dialog. Click Save button to open another dialog for saving configuration as a file. Vigor2130 Series User’s Guide...
Page 106 Linux platform will appear different windows, but the backup function is still available. Note: Backup for Certification must be done independently. The Configuration Backup does not include information of Certificate. Go to System Maintenance >> Configuration Backup. The following windows will be popped-up, as shown below. Vigor2130 Series User’s Guide...
Page 107: Syslog / Mail Alert
Web Configurator of the router or borrow debug equipments. Enable (Syslog Access…) Check the box to activate function of syslog. Router Name Type a name of this device. Server IP Address The IP address of the Syslog server. Vigor2130 Series User’s Guide...
Page 108 From the Syslog screen, select the router you want to monitor. Be reminded that in Network Information, select the network adapter used to connect to the router. Otherwise, you won’t succeed in retrieving information from the router. Vigor2130 Series User’s Guide...
Page 109: Time And Date
Select the time zone where the router is located. Add NTP server Click the button to add a new NTP server. Delete Click this button to remove an NTP server. Click OK to save these settings. Vigor2130 Series User’s Guide...
Page 110: Management
Subnet Mask - Represent a subnet mask allowed to login to the router. The Web Configurator may be used to restart your router for using current configuration. Click Reboot System from System Maintenance to open the following page. Vigor2130 Series User’s Guide...
Page 111: Firmware Upgrade
Note that this example is running over Windows OS (Operating System). Download the newest firmware from DrayTek's web site or FTP site. The DrayTek web site is www.draytek.com (or local DrayTek's web site) and FTP site is ftp.draytek.com.
Page 112 Vigor2130 Series User’s Guide...
Page 113: Admin Mode Operation
Hence, the NIC has reserved certain addresses that will never be registered publicly. These are known as private IP addresses, and are listed in the following ranges: Vigor2130 Series User’s Guide...
Page 114 However, the original Ethernet WAN still can be used and Load-Balance can be done in the router. Besides, 3G USB Modem also can be used as backup device. Therefore, when WAN is not available, the router will use 3.5G for supporting automatically. The supported 3G USB Vigor2130 Series User’s Guide...
Page 115: Internet Access
Modem will be listed on DrayTek web site. Please visit www.draytek.com for more detailed information. Below shows the menu items for WAN. This page allows you to set WAN configuration with different modes. Use the Connection Type drop down list to choose one of the WAN modes. The corresponding page will be displayed.
Page 116 DHCP allows a user to obtain an IP address automatically from a DHCP server on the Internet. If you choose DHCP mode, the DHCP server of your ISP will assign a dynamic IP address for your router automatically. It is not necessary for you to assign any setting, Vigor2130 Series User’s Guide...
Page 117 To choose PPPoE as the accessing protocol of the internet, please select PPPoE from the Internet Access menu. The following web page will be shown. Username Type in the username provided by ISP in this field. Password Type in the password provided by ISP in this field. Vigor2130 Series User’s Guide...
Page 118 It is available when the box of Enable is checked. Click Clone MAC Address. The result will be displayed in the field of MAC Address. After finishing all the settings here, please click OK to activate them. Vigor2130 Series User’s Guide...
Page 119 ISP does not provide it, the router will automatically apply default secondary DNS Server IP address: 194.98.0.1 to this field. Redial Policy If you want to connect to Internet all the time, you can choose Always On. Otherwise, choose Connect on Demand and Vigor2130 Series User’s Guide...
Page 120 ISPs. Modem Dial String Such value is used to dial through USB mode. Please use the default value. If you have any question, please contact to your ISP. PPP Username Type the PPP username (optional). Vigor2130 Series User’s Guide...
Page 121: Ports
If not, there will be no flow control in the port. It drops the packet if too much to handle. Current Rx: indicates whether pause frames on the port are obeyed. Vigor2130 Series User’s Guide...
Page 122: Backup
WAN connection type is not in 3G mode. When the WAN connection is broken, router will try to keep the connection with 3G mode. After WAN connection is recovered, router will disconnect the 3G connection automatically. Vigor2130 Series User’s Guide...
Page 123: Lan
MAC Address. The result will be displayed in the field of MAC Address. Local Area Network (LAN) is a group of subnets regulated and ruled by router. The design of network structure is related to what type of public IP addresses coming from your ISP. Vigor2130 Series User’s Guide...
Page 124 IP address. As a part of the public subnet, the Vigor router will serve for IP routing to help hosts in the public subnet to communicate with other public hosts or servers outside. Therefore, the router should be set as the gateway for public hosts. Vigor2130 Series User’s Guide...
Page 125: General Setup
Virtual LAN (VLAN) function and the rate of each. This page provides you the general settings for LAN. Click LAN to open the LAN settings page and choose General Setup. Vigor2130 Series User’s Guide...
Page 126: Ports
It can set the speed and duplex of the port. You can use the drop down list to choose the required speed for the router. If you have no idea in configuring speed, simple use the default setting, Vigor2130 Series User’s Guide...
Page 127 PerfectReach: Link up power savings enabled. Enabled: Both link up and link down power savings enabled. Refresh Click this button to refresh the information for LAN ports. After finishing all the settings here, please click OK to activate them. Vigor2130 Series User’s Guide...
Page 128: Mac Address Table
To add a new static MAC entry, click Add new static entry. A new entry will be shown as follows. Choose VLAN ID and type a new MAC address. Next, specify port member for this table. Finally, click OK to save the changes. Vigor2130 Series User’s Guide...
Page 129: Vlan
To add or remove a VLAN, please refer to the following example. VLAN 1 is consisted of hosts linked to P1 ~ P4. After checking the box to enable VLAN function, you will check the table according to the needs as shown below. Vigor2130 Series User’s Guide...
Page 130: Monitor Port
Check to set up the port(s) for being monitored. It only monitors the packets transmitted by the port you set up. Go to LAN to open setting page and choose Static Route. Index The number (1 to 10) under Index displays current static router. Vigor2130 Series User’s Guide...
Page 131 Main Router. Click the LAN - Static Route and click Add. Check the Enable box. Please add a static route as shown below, which regulates all packets destined to 192.168.10.0 will be forwarded to 192.168.1.2. Click OK. Vigor2130 Series User’s Guide...
Page 132: Bind Ip To Mac
When this function is enabled, all the assigned IP and MAC address binding together cannot be changed. If you modified the binding IP or MAC address, it might cause you not access into the Internet. Click LAN and click Bind IP to MAC to open the setup page. Vigor2130 Series User’s Guide...
Page 133: Nat
Save cost on applying public IP address and apply efficient usage of IP address. NAT allows the internal IP addresses of local hosts to be translated into one public IP address, thus you can have only one IP address on behalf of the entire internal hosts. Vigor2130 Series User’s Guide...
Page 134: Hardware Nat
Below shows the menu items for NAT. Hardware-base Acceleration Engine, also named Protocol Processing Engine API is the function that Draytek provides to extremely speed up the NAT performance. While the hardware acceleration mechanism is activated, most of the bandwidth usage will be concentrated on the specific sessions which increase transmission speed to get ultimately accelerated.
Page 135 Specify the ending port number of the service offered by the local host. Local Host Enter the private IP address of the local host. Local Port (optional) If it is configured, the forwarded traffic is mapped to this port on the local host. Vigor2130 Series User’s Guide...
Page 136: Dmz Host
Click DMZ Host to open the following page: Enable Check to enable the DMZ Host function. DMZ IP Enter the private IP address of the DMZ host, or click Choose PC to specify a suitable one. Vigor2130 Series User’s Guide...
Page 137: Firewall
The rate is 2^n, where n is equal to or less than 15, or "No Limit". The unit of the rate can be either pps (packets per second) or kpps (kilopackets per Vigor2130 Series User’s Guide...
Page 138: Ports Configuration
Disabled, and 1 to 10. The default value is Disabled. Counter Counts the number of frames that match this Access Control Entry (ACE). Refresh Click this button to refresh the number of the counter immediately. Vigor2130 Series User’s Guide...
Page 139 Rate limiter ID will be applied to WAN port and LAN port. Please specify a rate number for each ID. The default setting is “1”(packet per second). Rate Define the rate by choosing from the following drop down list. Vigor2130 Series User’s Guide...
Page 140: Access Control List
Ingress Port – define which port the packet coming from. The policy IDs are defined in Firewall>>Port Configuration. Each Policy ID might have more than one port grouped. Frame Type - Such option differs according to the selection Vigor2130 Series User’s Guide...
Page 141 Choose Ethernet Type as the Frame Type, you will get Ethernet Type Parameters option as the following: Ethernet Type Filter Choose Any to set the parameter with any value set by the router automatically or choose Specific to specify certain value (the range is 0x0000 to 0xFFFF). Vigor2130 Series User’s Guide...
Page 142 Type the Sender IP Address here. This option is available when you choose Host or Network as Sender IP Filter. Sender IP Mask Type the Sender IP Mask here. This option is available only when you choose Network as Sender IP Filter. Vigor2130 Series User’s Guide...
Page 143 (HLN) and protocol address length (PLN) settings. 0: means ARP/RARP frames/packets where the hardware address length is equal to Ethernet (0x06) and the protocol address length is equal to IPv4 (0x04) must not match this entry. Vigor2130 Series User’s Guide...
Page 144 Any: No source IP filter is specified. Host: Source IP filter is set to Host. Specify the source IP address in the Source IP Address field that appears. Network: Source IP filter is set to Network. Specify the Vigor2130 Series User’s Guide...
Page 145 ICMP Code Value If you choose Specific as ICMP Code Filter, you have to type the ICMP Type Value manually. The allowed range is 0 to 255. A frame meeting this ACE matches this ICMP value. Vigor2130 Series User’s Guide...
Page 146 Type the destination IP Address here. This option is available when you choose Host or Network as destination IP. Dest IP Mask Type the DIP Mask here. This option is available only when you choose Network as destination DIP. Vigor2130 Series User’s Guide...
Page 147 ACE matches this UDP source value. Dest. Port Range Type the value if you choose Range as the Dest. Port Filter. The allowed range is 0 to 65535. A frame meeting this ACE matches this UDP source value. Vigor2130 Series User’s Guide...
Page 148 Type the destination IP Address here. This option is available when you choose Host or Network as destination IP filter. Dest IP Mask Type the destination IP Mask here. This option is available only when you choose Network as destination IP filter. Vigor2130 Series User’s Guide...
Page 149 0: TCP frames where the FIN field is set must not be able to match this entry. 1: TCP frames where the FIN field is set must be able to match this entry. Any: Any value is allowed. Vigor2130 Series User’s Guide...
Page 150 Any: Any value is allowed TCP URG Specify the TCP "Urgent Pointer field significant" (URG) value for this ACE. 0: TCP frames where the URG field is set must not be able to match this entry. Vigor2130 Series User’s Guide...
Page 151 Host: Destination IP filter is set to Host. Specify the destination IP address in the destination IP Address field that appears. Network: Destination IP is set to Network. Specify the destination IP address and destination IP mask in the Vigor2130 Series User’s Guide...
Page 152: Bandwidth Management
To activate the function of limit session, simply click Enable and set the default session limit. Enable Click this button to activate the function of limit session. Disable Click this button to close the function of limit session. Vigor2130 Series User’s Guide...
Page 153: Bandwidth Limit
In the Bandwidth Management menu, click Bandwidth Limit to open the web page. To activate the function of limit bandwidth, simply click Enable and set the default upstream and downstream limit. Vigor2130 Series User’s Guide...
Page 154: Port Rate Control
Represent LAN or WAN interface. Policer Enabled Check this box to enable policer function. Policer Rate(Rx) Type the number for policer function. The default value is 500. It is restricted to 500-1000000 when the Policer Unit is set in Vigor2130 Series User’s Guide...
Page 155: Qos Control List
Vigor routers as edge routers of DS domain shall check the marked DSCP value in the IP header of bypassing traffic, thus to allocate certain amount of resource execute appropriate policing, classification or scheduling. The core routers in the backbone will do the same Vigor2130 Series User’s Guide...
Page 156 Display the value specified for the QCE. Traffic Class Display the class of the data transmission for the QCE. QoS Control List allows users to set up to five groups of QCL. Each QCL group can contain 12 QCE settings. Vigor2130 Series User’s Guide...
Page 157 If you choose VLAN ID as QCE Type, you have to type the ID number for it and specify traffic class from Low, Normal, Medium and High. If you choose TCP/UDP Port as QCE Type, you have to type the port number for it and specify traffic class from Low, Normal, Medium and High. Vigor2130 Series User’s Guide...
Page 158 If you choose DSCP as QCE Type, you have to type value for it and specify traffic class from Low, Normal, Medium and High. If you choose ToS as QCE Type, you have to specify priority class from Low, Normal, Medium and High. Vigor2130 Series User’s Guide...
Page 159: Ports Priority
ID, UDP/TCP port, IPv4/IPv6 DSCP or Tag Priority. Frames not matching any of the QCEs are classified to the default QoS class for the port. Port Indicate the interface for the physical port, WAN port, LAN port and Wireless Port. Vigor2130 Series User’s Guide...
Page 160: Qos Statistics
Use the drop down list to choose 1, 2, 4, or 8 as the queue weighted number. This page displays statistics for QoS setting. Click WAN/LAN link to check detailed information for each interface. Click WAN/LAN link to check detailed information for each interface. Vigor2130 Series User’s Guide...
Page 161 Display the number of 512 ~ 1023-byte frames in good and bad packets received. RX 1024- 1526 Bytes Display the number of 1024-1522-byte frames in good and bad packets received. RX 1527 Bytes Display the number of 1527-byte frames in good and bad packets received. Vigor2130 Series User’s Guide...
Page 162 Display the number of 1527-byte frames in good and bad packets transmitted. Tx Low Display the low queue counter of the packet transmitted. Tx Normal Display the normal queue counter of the packet transmitted. Tx Medium Display the medium queue counter of the packet received. Vigor2130 Series User’s Guide...
Page 163: Applications
Select the service provider for the DDNS account. Hostname Type in one domain name that you applied previously. Use the drop down list to choose the desired domain. Username Type in the login name that you set for applying domain. Vigor2130 Series User’s Guide...
Page 164: Schedule
Check to enable the schedule. Start Date Specify the starting date of the schedule. Start Time Specify the starting time of the schedule. Action Specify which action should be applied during the period of the schedule. Vigor2130 Series User’s Guide...
Page 165: Igmp Snooping
Snooping Enabled Check the box to enable this function. Unregistered IPMC… Check the box to enable unregistered IPMC traffic flooding Fast Leave Check the box to Fast Leave on the LAN port. Vigor2130 Series User’s Guide...
Page 166: Igmp Status
Windows XP and the router provide the associated support for MSN Messenger to allow full use of the voice, video and messaging features. Enable UPnP Enable UPnP function. You have to type the download and upload speed. Vigor2130 Series User’s Guide...
Page 167 Subsequently, such a facility forwards packets from the external ports of the router to the internal ports used by the application. The reminder as regards concern about Firewall and UPnP Can't work with Firewall Software Vigor2130 Series User’s Guide...
Page 168: Vpn And Remote Access
Enable IPSec VPN Pass-through If this checkbox is checked, the system f firewall will allow VPN (IPSec) remote access from WAN side to a VPN device on the LAN. Type the IP address of the VPN device in the field next to the checkbox. Vigor2130 Series User’s Guide...
Page 169: Pptp Remote Dial-In
IPSEC/L2TP. Allow PPTP Check this box to let the remote user connecting to this device through PPTP. Allow FTP Check this box to let the remote user connecting to FTP server via this router. Vigor2130 Series User’s Guide...
Page 170 To edit a user, click the name link under Username to open the following page. Modify the settings except Username and then click OK to save and exit it. If you want to remove such user settings, simply click Delete User. Vigor2130 Series User’s Guide...
Page 171: Ipsec Remote Dial-In
L2TP/IPSec –The range must not overlap the DHCP address range (if enabled), and must allow for at least one IP address. Example: 10.10.137.240-10.10.137.245. If you choose this type, please specify the IP address range for L2TP/IPSec mode. Vigor2130 Series User’s Guide...
Page 172: Remote Dial-In Status
Phase 2 (IPSec) - Negotiation IPSec security methods including Authentication Header (AH) or Encapsulating Security Payload (ESP) for the following IKE exchange and mutual examination of the secure tunnel establishment. You can find the summary table of all dial-in user status. Vigor2130 Series User’s Guide...
Page 173: Lan To Lan
ID, connection type (VPN connection - including PPTP, IPSec Tunnel) and corresponding security methods, etc. The router supports 2 VPN tunnels simultaneously and provides up to 2 profiles. The following figure shows the summary table. Vigor2130 Series User’s Guide...
Page 174 Display the status of the phase 2 IPSec ESP key exchange. ESP Alg Display the encryption and authentication algorithm used during phase 2 of the VPN connection Establishment. This algorithm is used for transporting data, and the choice will affect the performance of the VPN tunnel. Vigor2130 Series User’s Guide...
Page 175 IPSec session. However, the Aggressive mode is faster. The default value in Vigor router is Main mode. Type This group of fields is applicable for IPSec Tunnels. Different type will bring out different requirement of information. Vigor2130 Series User’s Guide...
Page 176 Propose the local available algorithms to the VPN peers, and get its feedback to find a match. Perfect Forward Secrecy The IKE Phase 1 key will be reused to avoid the computation complexity in phase 2. The default value is inactive this function. Vigor2130 Series User’s Guide...
Page 177: Wireless Lan
Complete Security Standard Selection: To ensure the security and privacy of your wireless communication, we provide several prevailing standards on market. Vigor2130 Series User’s Guide...
Page 178: General Setup
Check the box to enable the wireless function. SSID Broadcast Choose Show to make the SSID being seen by wireless clients. Choose Hide to prevent from wireless sniffing and make it harder for unauthorized clients or STAs to join your wireless LAN. Vigor2130 Series User’s Guide...
Page 179 It means the identification of the wireless LAN. SSID can be any text numbers or various special characters. The default SSID is "DrayTek". We suggest you to change it. Wireless Mode Choose the wireless mode for this router. At present, only 802.11B/B/N mix is available.
Page 180 Accepts only WPA clients and the encryption key should be entered in PSK. The WPA encrypts each frame transmitted from the radio using the key, which either PSK (Pre-Shared Key) entered manually in this field below or automatically negotiated via 802.1x authentication. Vigor2130 Series User’s Guide...
Page 181 Choose the WPA algorithm, TKIP, AES or Auto. Server IP Address Enter the IP address of RADIUS server. Destination Port The UDP port number that the RADIUS server is using. The default value is 1812, based on RFC 2138. Vigor2130 Series User’s Guide...
Page 182 Start PBC button or using PIN Code. On the side of Vigor 2130 series which served as an AP, press WPS button once on the front panel of the router or click Start PBC on web configuration interface. On the side Vigor2130 Series User’s Guide...
Page 183: Access Control
MAC addresses to control their access rights (deny or allow). Filter Type Choose the rule for the MAC addresses displayed in this page. Allow List – all the MAC address of wireless clients listed here are allowed to do wireless connection. Vigor2130 Series User’s Guide...
Page 184: Station List
Based on the scanning result, users will know which channel is clean for usage. Note: During the scanning process (about 5 seconds), no client is allowed to connect to Vigor. The table will list channel, SSID, BSSID, Security and the Signal strength of working APs in the neighborhood. Vigor2130 Series User’s Guide...
Page 185: Usb Application
FAT32 only. Therefore, before connecting the USB diskette into the Vigor router, please make sure the memory format for the USB diskette is FAT16 or FAT32. It is recommended for you to use FAT32 for viewing the filename completely (FAT16 cannot support long filename). Vigor2130 Series User’s Guide...
Page 186: Ftp User Management
OK, the router will create the specific/new folder in the USB diskette. In addition, if the user types “/” here, he/she can access into all of the disk folders and files in USB diskette. Vigor2130 Series User’s Guide...
Page 187: Disk Status
Click this button to refresh the disk status. This page can define the folder which will be shared while Samba File Sharing is enabled. To add a new entry for disk sharing, please click Add a New Entry to open the following page. Vigor2130 Series User’s Guide...
Page 188 All Users Read-only - everyone has read-only access to the share disk. All Users Read-write - everyone has read-write access to the share disk. Specific Users – Only specific user(s) can access into the share disk. Vigor2130 Series User’s Guide...
Page 189: Ipv6
Link-Local address is used for communicating with neighbouring nodes on the same link. It is defined by the address prefix fe80::/10. You don't need to setup Link-Local address manually for it is generated automatically according to your MAC Address. Vigor2130 Series User’s Guide...
Page 190 Type your IPv6 secondary DNS Server address here. DHCPv6 client type would use DHCPv6 protocol to obtain IPv6 address from server. Primary DNS Server Type primary DNS Server address here. Secondary DNS Server Type secondary DNS Server address here. Vigor2130 Series User’s Guide...
Page 191 IPv6-in-IPv4 Tunnel- Let the broker choose the tunnel mode appropriate for the client. IPv6-in-IPv4 (Native) - Request an IPv6 in IPv4 tunnel. IPv6-in-IPv4 (NAT Traversal - Request an IPv6 in UDP of IPv4 tunnel (for clients behind a NAT). Vigor2130 Series User’s Guide...
Page 192 If_prefix Display LAN interface name. interface that will be configured with the first 64 of the received prefix from the broker and the router advertisement daemon is started to advertise that prefix on the if_prefix interface. Vigor2130 Series User’s Guide...
Page 193: Ipv6 Lan Setup
One is RADVD(stateless) and the other is DHCPv6 Server (Stateful). DHCPv6 Server- DHCPv6 Server could assign IPv6 address to PC according to the Start/End IPv6 address configuration. IPv6 Start Address/IPv6 End Address- Type the start and end address for IPv6 server. Vigor2130 Series User’s Guide...
Page 194: Ipv6 Firewall Setup
Display the destination IP address of such rule. Source Port Display the source port number of such rule. Destination Port Display the destination port number of such rule. Action Display the status (accept or drop) of such rule. Vigor2130 Series User’s Guide...
Page 195 Type the subnet mask here if you choose Subnet as Source IP Type. Destination IP Type Determine the IP type as the destination. Destination IP Type the IP address here if you choose Single as Destination IP Type. Vigor2130 Series User’s Guide...
Page 196 You are using IPv6 from 2001:5c0:1503:7400:30e4:139d:53c8:3a1e Set firewall rule to block all TCP traffic from this IP address. Open IPv6 >> IPv6 Firewall Setup and press Add New Rule. In the following dialog, please configure the page with the following values. Vigor2130 Series User’s Guide...
Page 197: Ipv6 Routing
(usually counted in Metric Display the hops). It is not used by recent kernels, but may be needed by routing daemons. Expires Display the lifetime of the route. he largest size (in bytes) of a packet. Display t Vigor2130 Series User’s Guide...
Page 198: Ipv6 Neighbour
IPv6 TSPC status web page could help you to diagnose the connection status of TSPC. TSPC log contains some debug information from program. If TSPC has not configured properly, the router will display the following page when the user tries to connect through TSPC connection. Vigor2130 Series User’s Guide...
Page 199 When the router detects all the information, the screen will be shown as follows. One set of TSPC prefix and prefix length will be obtained after the connection between TSPC and Tunnel broker built. Connection Status It will bring out different pages to represent IPv6 disconnection, connecting and connected. Vigor2130 Series User’s Guide...
Page 200 Users can use such IP for connecting to IPv6 network. When your PC obtains the IPv6 address, please connect to http://www.ipv6.org. If your PC access Internet via IPv6 connection, your IPv6 address will be shown on the web page immediately. Refer to the following figure. Vigor2130 Series User’s Guide...
Page 201: User
Check this box to let the remote user connecting to FTP server via this router. Delete User Remove settings on current page and delete the user. This button is not available for new configuration by pressing Add a New User. Vigor2130 Series User’s Guide...
Page 202 To edit a user, click the name link under Username to open the following page. Modify the settings except Username and then click OK to save and exit it. If you want to remove such user settings, simply click Delete User. Vigor2130 Series User’s Guide...
Page 203: System Maintenance
Display the date and time of the current firmware build. Hardware NAT Version Display the hardware acceleration NAT version. System Date Display current time and date for the system server. System Uptime Display the connection time for the system server. LAN------- Vigor2130 Series User’s Guide...
Page 204: System Password
Type in new password in this filed. Confirm Password Type in the new password again. When you click OK, the login window will appear. Please use the new password to access into the web configurator again. Vigor2130 Series User’s Guide...
Page 205: User Password
Type a key arbitrarily for encrypting the file. Keep the key in mind. You will need it whenever you want to restore such file. Click Backup button to get into the following dialog. Click Save button to open another dialog for saving configuration as a file. Vigor2130 Series User’s Guide...
Page 206 Linux platform will appear different windows, but the backup function is still available. Note: Backup for Certification must be done independently. The Configuration Backup does not include information of Certificate. Go to System Maintenance >> Configuration Backup. The following windows will be popped-up, as shown below. Vigor2130 Series User’s Guide...
Page 207: Syslog/Mail Alert
Enable (Syslog Access…) Check “Enable” to activate function of syslog. Router Name Assign a name of this device. Server IP Address The IP address of the Syslog server. Destination Port Assign a port for the Syslog protocol. Vigor2130 Series User’s Guide...
Page 208 From the Syslog screen, select the router you want to monitor. Be reminded that in Network Information, select the network adapter used to connect to the router. Otherwise, you won’t succeed in retrieving information from the router. Vigor2130 Series User’s Guide...
Page 209: Time And Date
Select the time zone where the router is located. Add NTP server Click the button to add a new NTP server. Delete Click this button to remove an NTP server. Click OK to save these settings. Vigor2130 Series User’s Guide...
Page 210: Management
Subnet Mask - Represent a subnet mask allowed to login to the router. The Web Configurator may be used to restart your router for using current configuration. Click Reboot System from System Maintenance to open the following page. Vigor2130 Series User’s Guide...
Page 211: Firmware Upgrade
Note that this example is running over Windows OS (Operating System). Download the newest firmware from DrayTek's web site or FTP site. The DrayTek web site is www.draytek.com (or local DrayTek's web site) and FTP site is ftp.draytek.com.
Page 212: Diagnostics
Ping Size Type in the payload size of the ICMP packet. Values range from 8 bytes to 1400 bytes. Start Click this button to start the ping work. The result will be displayed on the screen. Vigor2130 Series User’s Guide...
Page 213: Routing Table
Display count of lookups for the route. Depending on the use of -F and –C, this will be either route cache misses (-F) or hits (-C). Iface Display interface to which packets for this route will be sent. Refresh Click it to reload the page. Vigor2130 Series User’s Guide...
Page 214: System Log
Check it to enable auto-refresh function. Reverse Check it to have newest log entries presented first. Refresh Click it to reload the page. This page offers an overview of general traffic statistics for all connecting ports. Vigor2130 Series User’s Guide...
Page 215: Detailed Statistics
Click it to reload the page. Clear Click it to clear the counters for all ports. This page display detailed statistics for WAN/LAN interface. Rx Packets Display the counting number of the packet received. Rx Octets Display the total received bytes. Vigor2130 Series User’s Guide...
Page 216 Tx Unicast Display the show the counting number of the transmitted unicast packet. Tx Multicast Display the show the counting number of the transmitted multicast packet. Tx Broadcast Display the counting number of the transmitted broadcast packet. Vigor2130 Series User’s Guide...
Page 217: Mac Address Table
The button >> will use the last entry of the currently displayed VLAN/MAC address pairs as a basis for the next lookup. When the end is reached the text "no more entries" is shown in the displayed table, use the l<< button to start over. Vigor2130 Series User’s Guide...
Page 218 Display the MAC address of that entry. Port Members Display the port of that entry. Auto-refresh Check it to enable auto-refresh function. Refresh Click it to reload the page. Clear Click it to clear the whole table. Vigor2130 Series User’s Guide...
Page 219: Dhcp Table
It displays the MAC address for the specified PC that DHCP assigned IP address for it. Expire Time It displays the leased time of the specified PC. Auto-refresh Check it to enable auto-refresh function. Refresh Click it to reload the page. Vigor2130 Series User’s Guide...
Page 220: Data Flow Monitor
If "HNAT" is shown, that means the transmission is through Hardware NAT can't be computed. Sessions Display the session number that you specified in Limit Session web page. Action Block - can prevent specified PC accessing into Internet within 5 minutes. Vigor2130 Series User’s Guide...
Page 221: Ports State
Auto-refresh Check it to enable auto-refresh function. Refresh Click it to reload the page if you change the LAN port connection. Or you can check Auto-refresh to reload the page by the system automatically. Vigor2130 Series User’s Guide...
Page 222 This page is left blank. Vigor2130 Series User’s Guide...
Page 223: Trouble Shooting
Turn on the router. Make sure the ACT LED blink once per second and the correspondent LAN LED is bright. If not, it means that there is something wrong with the hardware status. Simply back to “1.3 Hardware Installation” to execute the hardware installation again. And then, try again. Vigor2130 Series User’s Guide...
Page 224 Go to Control Panel and then double-click on Network Connections. Right-click on Local Area Connection and click on Properties. Select Internet Protocol (TCP/IP) and then click Properties. Vigor2130 Series User’s Guide...
Page 225 Select Obtain an IP address automatically and Obtain DNS server address automatically. Double click on the current used MacOs on the desktop. Open the Application folder and get into Network. On the Network screen, select Using DHCP from the drop down list of Configure IPv4. Vigor2130 Series User’s Guide...
Page 226: Pinging The Router From Your Computer
Open the Application folder and get into Utilities. Double click Terminal. The Terminal window will appear. Type ping 192.168.1.1 and press [Enter]. If the link is OK, the line of “64 bytes from 192.168.1.1: icmp_seq=0 ttl=255 time=xxxx ms” will appear. Vigor2130 Series User’s Guide...
Page 227: Checking If The Isp Settings Are Ok Or Not
Open WAN>>Internet Access page and then check whether the ISP settings are set correctly. Use the Connection Type drop down list to choose Static IP/DHCP/PPPoE/PPTP/L2TP for reviewing the settings that you configured previously. Vigor2130 Series User’s Guide...
Page 228 Check if IP Address, IP Mask and IP Router are set correctly (must identify with the values from your ISP). Choose PPPoE as the connection type. Check if Username and Password are set correctly (must identify with the values from your ISP). Vigor2130 Series User’s Guide...
Page 229: Forcing Vigor Router Into Tftp Mode For Performing The Firmware Upgrade
Indicate the firmware location. Note: There are two firmware types. The .rst firmware format will make the configurations be back to default settings after upgrading firmware. The .all firmware format will remain the former configurations after upgrading firmware. Vigor2130 Series User’s Guide...
Page 230 10. Input the Password if you have set one, then click Send. 11. There is a bar showing the upgrading process. 12. When the firmware upgrade is successful, the following window will pop up. Vigor2130 Series User’s Guide...
Page 231 Transfer Abort ! appears, please check if the firmware you download is correct for your Vigor router. Note: Please turn off the Firewall protection while upgrading the firmware with Windows Vista. The Firewall function can be turned off via Control Panel >> Security Center >> Firewall. Vigor2130 Series User’s Guide...
Page 232: Backing To Factory Default Setting If Necessary
5 seconds. When you see the ACT LED blinks rapidly, please release the button. Then, the router will restart with the default configuration. After restore the factory default setting, you can configure the settings for the router again to fit your personal request. Vigor2130 Series User’s Guide...
Page 233: Contacting Your Dealer
If the router still cannot work correctly after trying many efforts, please contact your dealer for further help right away. For any questions, please feel free to send e-mail to support@draytek.com. Vigor2130 Series User’s Guide...

Draytek Vigor2130 Series User Manual

Preface

Configuring Basic Settings

User Mode Operation

Admin Mode Operation

Trouble Shooting

Quick Links

Related Manuals for Draytek Vigor2130 Series

Summary of Contents for Draytek Vigor2130 Series

Table of Contents
