Fax card removal

CAUTION
This product contains a lithium battery. THERE IS A RISK OF EXPLOSION IF THE BATTERY
IS REPLACED BY AN INCORRECT TYPE. Discard used batteries according to the battery
manufacturer's instructions and local regulations.
1.
Remove the rear door and cover. See
2.
Remove the right side printer cover. See
3.
Remove the two screws (A) securing the fax card to the printer frame.
4.
Disconnect the cable (B) from the controller board.
5.
Remove the fax card.
"Rear door and cover removal" on page
"Right side printer cover removal" on page
7013-XXX
4-67.
4-71.
4-23
Repair information
