Left side printer cover removal
1.
Remove the rear door and cover. See
2.
Remove the left side scanner cover. See
3.
Remove the screw (A) from the font of the printer.
4.
Press in on the tabs (B).
"Rear door and cover removal" on page
"Left side scanner cover removal" on page
A
B
7013-XXX
4-67.
4-35.
4-33
Repair information
