MENU SCREEN

QSO/RX Log items

QSO Log
QSO/RX Log > QSO Log
Select whether or not to make a communication log on
an SD card.
The communication log can be made on an SD card,
and saved in the "csv" format.
Be sure to insert the SD card into the card slot before
attempting to make the log.
• OFF: The QSO Log function is OFF.
• ON: The transceiver makes a log on the SD card.
The transceiver starts making a log when you
begin talking.
NOTE:
• The folder name is automatically created, as
[ID-5100\QsoLog].
• The file name is automatically created, as shown in
the example below:
Log start date and time: 2014/4/1 15:30:00
File name: 20140401_153000.csv
• The log contents cannot be displayed on the trans-
ceiver.
• You can view the log contents on a PC.
RX History Log
QSO/RX Log > RX History Log
Select whether or not to make a DV mode's receive his-
tory log on an SD card.
The receive history log can be made on an SD card,
and saved in the "csv" format. Be sure to insert the SD
card into the transceiver before attempting to make the
log.
• OFF: The RX History Log function is OFF.
• ON: The transceiver makes a DV mode's receive his-
tory log on the SD card.
The transceiver starts making a receive history
log when you finish talking.
NOTE:
• The folder name is automatically created, as
[ID-5100\RxLog].
• The file name is automatically created, as shown in
the example below:
Log start date and time: 2014/4/1 15:30:00
File name: 20140401_153000.csv
• The log contents cannot be displayed on the trans-
ceiver.
• You can see the log contents on a PC.
Separator/Decimal
(Default: OFF)
QSO/RX Log > CSV Format > Separator/Decimal
Select the separator and the decimal character for the
CSV format.
• Sep [,] Dec [.]: Separator is "," and Decimal is "."
• Sep [;] Dec [.]: Separator is ";" and Decimal is "."
• Sep [;] Dec [;]: Separator is ";" and Decimal is ";"
* The default value may differ, depending on the trans-
ceiver version.
Date
QSO/RX Log > CSV Format > Date
Select the date format between "yyyy/mm/dd," "mm/dd/
yyyy" and "dd/mm/yyyy." (y: year, m: month, d: day)
* The default value may differ, depending on the trans-
ceiver version.
(Default: OFF)
12-49
(Default: Sep [,] Dec [.]*)
(Default: mm/dd/yyyy*)
