12
MENU SCREEN
GPS items (Continued)
2. When the caller's TX format is D-PRS Position
(Mobile station)
Displays the caller's direction from your
Compass*
position
Latitude Displays the caller's latitude
Longitude Displays the caller's longitude
Displays the grid locator based on the
GL latitude and longitude of the caller's
position.
ALT Displays the caller's altitude
Displays the caller's distance from your
DST
position
COURSE Displays the caller's direction over ground
SPEED Displays the caller's speed
Symbol Displays the caller's D-PRS symbol
SSID Displays the caller's SSID
Displays the time that the caller acquired
GPS Time Stamp
the position data.
Call sign Displays the caller's call sign (with SSID)
3. When the caller's TX format is D-PRS Position
(Base station)
Displays the caller's direction from your
Compass*
position
Latitude Displays the caller's latitude
Longitude Displays the caller's longitude
Displays the grid locator based on the
GL latitude and longitude of the caller's
position.
ALT Displays the caller's altitude
Displays the caller's distance from your
DST
position
POWER Displays the caller's TX power level
HEIGHT Displays the height of caller's antenna
GAIN Displays the gain of caller's antenna
Displays the direction of caller's antenna
DIRECT
was pointing
Symbol Displays the caller's D-PRS symbol
SSID Displays the caller's SSID
Displays the time that the caller acquired
GPS Time Stamp
the position data.
Call sign Displays the caller's call sign (with SSID)
*These items can be selected in the Quick Menu screen.
4. When the caller's TX format is D-PRS Object/Item
Displays the Object/Item station's direction
Compass*
from your position
Latitude Displays the Object/Item station's latitude
Displays
Longitude
longitude
Displays the grid locator based on the
GL latitude and longitude of the Object/Item
station's position.
ALT Displays the Object/Item station's altitude
Displays the Object/Item station's distance
DST
from your position
Displays the Object/Item station's direction
COURSE
over ground
SPEED Displays the Object/Item station's speed
Displays the Object/Item station's TX
POWER
power level
Displays the height of Object/Item station's
HEIGHT
antenna
Displays the gain of Object/Item station's
GAIN
antenna
Displays the direction that the Object/Item
DIRECT
station's antenna was pointing
Displays the Object/Item station's D-PRS
Symbol
symbol
SSID Displays the caller's SSID
Displays the time that the caller sent the
GPS Time Stamp
Object station's data.
Call sign Displays the caller's call sign (with SSID)
When the object or item station is disabled, "KILLED"
appears.
12-33
the Object/Item station's
