Quick Set mode items

NOTE: The default settings described below are for the USA version transceiver. The default settings may differ,
depending on your transceiver version.
RF Power
Sets the RF output power.
• Range: L (minimum), 1 ~ 99, and H (maximum)
Mic Gain
Adjusts the microphone gain.
• Range: 0 ~ 99, and H (maximum)
VOX Gain
Adjusts the VOX gain for the VOX (Voice Activated transmit) function.
• Range: 0 ~ 99
VOX Delay
Adjusts the VOX delay time.
• Range: 0 ~ 20 (2.0 seconds) in 0.1 second steps.
Anti VOX Level
Adjusts Anti-VOX gain for the VOX operation.
• Range: 0 ~ 99
CW Pitch
Sets the CW tone pitch
• Range: 30 (300 Hz) ~ 90 (900 Hz) in 10 Hz steps.
BK-IN
Sets the Break-in type for the CW operation.
• Option: oF (OFF), SE (Semi break-in), FL (Full break-in)
BK-IN Delay
Sets the Break-in delay time for the CW semi break-in operation.
• Range: 2 ~ 13 (dots.)
Key Speed
Adjusts the CW keying speed.
• Range: 6 ~ 60 (wpm.)
L Some values cannot be set between 6 and 60.
Key Ratio
Sets the CW key ratio (or weight.)
• Range: 28 (2.8) ~ 45 (4.5.)
RTTY Mark Tone
Selects the Mark tone frequency for RTTY operation.
• Option: 1275, 1615, 2125 (Hz)
RTTY Shift
Selects the RTTY shift.
• Option: 170, 200, 425, 850 (Hz)
Dimmer
Selects the display backlight brightness.
• Option: oF (OFF), Lo (Dim), HI (Bright)
6
SET MODE
(Default: H)
(Default: 50)
(Default: 50)
(Default: 10 (1.0 second))
(Default: 50)
(Default: 60 (600 Hz))
(Default: oF)
(Default: 7)
(Default: 20)
(Default: 30 (3.0)
(Default: 2125)
(Default: 170 Hz)
(Default: HI)
