Examine the print test sheet as follows:
1. Check that the numbered scale is not broken at any point
and that the black areas do not present any horizontal
white lines: if these conditions, which confirm that the car-
tridge has been inserted correctly and is working properly,
are respected, set the value 1. The fax machine returns to its
initial stand-by mode and is ready for use. The display shows
"AUTOMATIC 00" on the first line and the current date and
time on the second line.
2. On the other hand, if there are any breaks or white lines
present, set 0 to clean the nozzles again: if the new print test
continues to be unsatisfactory, repeat the procedure another
time. At this point:
• if the printing quality still does not meet your expectations,
clean the electrical contacts as indicated in the "To clean
the electrical contacts of the print cartridge" section
of the "Maintenance operations" chapter.
• if the printing quality is satisfactory, set the value 1. The fax
machine returns to its initial stand-by mode and is ready for
use.
When the cartridge is about to run out of ink, the display
shows:
and for some models, the fax machine prints, on a sheet
loaded automatically, the indication that the ink is about to
run out.
When there is no ink left, the display shows:
To replace the cartridge, see the section "Maintenance op-
erations ".
To buy new print cartridges, see the corresponding code
at the end of the manual.
T
O PRINT THE MENU AND ITS FUNCTIONS
As it is always useful to have the menu structure and its
functions close at hand, we recommend you print it out.
1. Press the key:
The display shows:
2. Press the keys
until the display shows:
3. To confirm the setting, press the key:
Having printed the report, the fax machine automati-
cally returns to its initial stand-by mode.
T
RANSMISSION
If you follow the procedures described below, you can imme-
diately use the fax machine to carry out simple trans-
mission operations. In any case, if these procedures are
not enough for you, see the "Transmission and reception
operations" chapter, which provides a detailed description
of all the transmission modes and how to program the phone
book.
W
HAT DOCUMENTS MAY BE USED
For any type of tansmission, the document has to be
placed in the ADF.
CHARACTERISTICS OF THE ORIGINAL
• Width 210 mm
• Length min. 105 mm - max. 600 mm
• Unit weight 70 - 90 gr/m
For documents of different sizes from those specified above,
photocopy the original onto A4 sheets or another supported
format and send the copy.
1
Once the document has been inserted in the automatic docu-
ment feeder (ADF), the display shows on the top line:
and on the bottom line, the default contrast value: "NORMAL".
If you do not perform any operation within about two minutes
of inserting the document in the automatic document feeder
(ADF), the fax machine will automatically unload the docu-
ment from the feeder.
2
(max. 5 sheets)
1. Place the document in the auto-
matic document feeder (ADF)
with the side to be sent face down
(A).
Place the document against the
right-hand side of the feeder: see
the mark printed on the fax ma-
chine's casing (B).
