2. To hear the dialling tones, press the key:
The display shows:
and the length of the transmission in minutes and sec-
onds in the top right-hand corner.
3. To dial the number of the correspondent to whom you
wish to send the document, press the keys:
-
4. As soon as you hear the tone of your correspondent's
fax machine, press the key:
Transmission is started. The message "CONNECTING"
appears on the display.
If the document is sent correctly, once this operation has
been completed, the display will show the message "TX
COMPLETED" for a moment.
T
O SEND A DOCUMENT WITH THE RECEIVER RAISED
1. Insert the document in the automatic document feeder
(ADF).
The display shows on the top line:
and on the bottom line, the default contrast value: "NOR-
MAL".
The initial resolution value is: "
If you want, change the contrast and resolution values
as described previously.
2. Lift the receiver to engage the line.
The display shows:
and the length of the transmission in minutes and sec-
onds in the top right-hand corner.
3. To dial the number of the correspondent to whom you
wish to send the document, press the keys:
-
If your correspondent's fax machine is set up for auto-
matic reception, you will hear the fax machine sig-
nal.
If it is set up for manual reception, the correspondent
himself will answer so you can ask him to press the
start key on his fax machine, after which you will hear
the fax machine signal.
4. To start sending, press the key:
The message "CONNECTING" appears on the dis-
play.
5. Hang up.
If the document is sent correctly, once this operation has
been completed, the display will show the message "TX
COMPLETED" for a moment.
If no connection is established due to errors on the line or
because the correspondent's number is busy, the fax ma-
chine automatically redials the number of times set by
the telephone system of the telephone company.
The fax machine's memory allows you to send a document
(even at a preset time: "Delayed transmission") to several
correspondents (max. 10): "Broadcast transmission". See

"To send a document from the memory".

" (standard).
A
UTOMATIC REDIAL
T
O SEND A DOCUMENT TO SEVERAL CORRESPONDENTS
T
O SEND A DOCUMENT FROM THE MEMORY
1. Insert the document in the automatic document feeder
(ADF).
The display shows on the top line:
and on the bottom line, the default contrast value: "NOR-
MAL".
The initial resolution value is: "
If you want, change the contrast and resolution values
as described previously.
2. Press the key:
The display shows:
3. Press the keys
until the display shows:
4. Press the key:
The display shows:
5. Press the key:
The fax machine starts to save the document. Once
saved, the display shows the message "DOC.N. XXXX"
and then:
6. To type the time at which you wish to send the docu-
ment, for example "16:50", press the keys:
-
" (standard).
