Chapter 13

Placing the HP NetServer in the Rack

Use this procedure to position the HP NetServer into the extended slides and
secure the chassis to the slides.
1. Ensure you have extended the anti-tip foot from the rack, before continuing
this procedure.
2. Pull out both slides until the slide members are fully extended.
The slides click into position when locked. This locked position prevents
the slides from moving back into the rack, unless the release latches are
pressed as shown in Figure 13-7.
WARNING
If you have not already done so, pull the rack's anti-tip foot
forward out of the bottom of the rack to prevent rack
instability while mounting the HP NetServer. Failure to do so
could result in injury and equipment damage. Figure 13-5
shows the anti-tip foot in position.
Leveler
Screws (4)
158
Slide Member
Figure 13-7. Pulling Out the Slides
Alternative Rack Mounting
Slide Member
