Chapter 3
Remove the
PCI Access Panel
5. To replace the PCI access panel, lower it onto the top cover, about ½ inch
to the rear of its normally closed position. See Figure 3-6.
6. Push the PCI access panel forward until the tabs along its front edge line
up with the screw holes on the top cover.
7. Re-attach the two T-15 Torx
Be sure you use the short T-15 Torx
36
Opening and Closing the HP NetServer
Figure 3-7. Lifting Off the Access Panel
®
screws to the top cover.
®
screws.
