Clearing CMOS

If you need to manually reset your CMOS settings to their
factory state, change the jumper setting on block JBAT1 after
the system has been unplugged. The following table lists the
jumper settings, and the function of each setting. Move the
jumper back to pins 1-2 (to keep future CMOS changes) after
waiting approximately five seconds.
JBAT1
1-2
2-3

Setting the Power On Mode

Your system can be jumpered to start up in two ways:
T
when the power button is pressed, or
T
when the power cable is connected ("Immediate Boot
Up").
To change way your system starts up, change the jumper
setting on block JP1. The following table lists the jumper
settings, and the function of each setting.
Power On Mode Jumper Settings
JP1
1-2
none
CMOS Clear Jumper Settings
Function
Keeps CMOS changes.
Clears CMOS changes.
Function
Boot up when power button is pressed.
Immediate boot up when power cable is
connected.
Configuring the System 3-37
