Installing a 3 1/2-Inch Hard Drive — Desktop
The desktop system has an internal hard drive bay located
near the right rear corner of the chassis, above the power
supply. It also has an accessible 3 1/2-inch bay that can
accommodate a second diskette drive, or a second hard drive.
You can upgrade the system by replacing the existing hard
drive, or by adding a hard drive to the 3 1/2-inch accessible
device bay. (For instructions on adding an additional hard
drive, see "Installing an Additional 3 1/2-Inch Device —
Desktop").
To install a 3 1/2-inch device in the 3 1/2-inch internal device
bay, proceed as follows.
1. Follow the preinstallation instructions that come with
your device, such as setting jumpers.
See "Preparing the Device" for device preparation
information.
2. Remove the system unit cover (see "Removing the Small
Desktop or Desktop Cover").
3. If a currently installed hard drive is being replaced:
T
Label the IDE device signal and power cables
connected to the drive and then disconnect them.
T
Remove the two screws securing the internal hard
drive (see the following figure).
T
Lift the internal hard drive out of its bracket over the
power supply.
5-92 Installing Options
