Cable the network board for Wake-On LAN as follows.
1. Remove the cover.
T
In a small desktop or desktop system, see "Removing
the Small Desktop or Desktop Cover."
T
In a minitower system, see "Removing the Minitower
Side Covers."
2. Locate the Wake-ON LAN connector on the riser board.
See one of the following figures:
T
"Riser board auxiliary cable connectors — small
desktop"
T
"Riser board auxiliary cable connectors — desktop"
T
"Riser board auxiliary cable connectors —
minitower."
3. If necessary, remove any expansion boards that may be in
the way (see "Installing and Removing Expansion
Boards").
4. Connect one end of the Wake-ON LAN cable to its
connector on the riser board.
5. Connect the other end of the Wake-ON LAN cable to the
network board (see the documentation that comes with
the option).
6. Replace any expansion board (see "Installing and
Removing Expansion Boards").
7. Replace the cover(s):
T
For a small desktop or desktop system, see
"Replacing the Small Desktop or Desktop Cover."
T
For a minitower system, see "Replacing the
Minitower Side Covers."
Installing Options 5-75
