6. Grasp the two board handles and pull the board out
further if you cannot access to the components you are
upgrading. If you need to replace the board, see
"Removing the System Board — Minitower" later in this
chapter.
Opening the chassis floor — minitower
A – Screw
B – Top Edge of Floor

Closing the Chassis Floor

To close the chassis floor, proceed as follows.
1. If the system board was partially slid out for access to
board components, slide it back into the chassis using the
two board handles.
If the system board was removed, see "Replacing the
System Board — Minitower" for replacement procedures.
2. Pivot the floor up against the chassis and press the floor
against the chassis until the floor latches in place. Closing
the floor also plugs the system board into the riser board.
5-20 Installing Options
C – Chassis Feet
D – Chassis Floor
