On CP1L units with 14-point I/O, interrupt inputs can be allocated to contacts 0.04
to 0.07.
Input interrupt 0 (CP1E: 4) will be allocated to contact 0.04. The interrupt task
executed by input interrupt 0 (CP1E: 4) is task No.140 (CP1E: No.4).
Sensor input 3 0.02
Sensor input 2 0.01
Sensor input 1 0.00
PASS output 100.00
NG output 100.01
PLC Setup
Set contact 0.04 to be [Interrupt].
1.
Open the PLC Settings dialog box.
2.
Click the Built-in Input tab.
3.
On the IN0 (CP1E: IN4) drop-down list for [Interrupt Input], select [Interrupt].
While the sensor input contact is 0.04, setup is performed for [IN0 (CP1E:
IN 4)] since the interrupt input setting is set to 0 (CP1E: 4).
4.
Close the PLC Settings dialog box.
5.
To apply changes made to the PLC settings, turn the PLC power ON.
A-4 CP1L Programming Examples
Sensor input (interrupt input 0) 0.04
RESET input 0.05
CP1L
NG output sensor input 3 100.04
NG output sensor input 2 100.03
NG output sensor input 1 100.02
