Epson Stylus Photo R2000s Series Service Manual page 230

Stylus Photo R1900/R2880/R2000/R2000s/SC-P400 Series
MAINTENANCE MENU
To display the maintenance menu, click the [Maintenance] button on the main
screen.
1
Figure 9-21. Maintenance menu
SC-P400 Series
(1)
(2)
(3)
(4)
2
3
4
Adjustment
Table 9-13. Details of the maintenance menu
Item
Main screen button Goes back to the main screen.
Nozzle check button Prints a nozzle check pattern.
Select a cleaning level among CL1, CL2, CL3, and
CL4 and run it. (Level selection available only in the
Head cleaning button
service mode. Basically use CL1, and if not
improved much, raise the level and try again.)
Restore Default Calibration Overwrite the data in the User Color ID area back to
button the saved data in the Production Color ID area.
x
Revision I
Description
230
