Extron electronics MTPX Plus Series User Manual page 58

Operation, cont'd
4.
Figure 3-32 — Assign inputs and outputs
5.
Figure 3-33 — Select an I/O group
6.
Figure 3-34 — Assign inputs and outputs
3-26 MTPX Plus Twisted Pair Matrix Switchers • Operation
Press and release the Input 1 through 4 and Output 1 through 4 buttons
(figure 3-32).
Press and release the Input 1 through Input 4 buttons.
The selected buttons light green.
1 2 3 4 5
17 18 19 20 21 22 23 24 31 32
Press and release the Output 1 through Output 4 buttons.
The selected buttons light green.
1 2 3 4 5
17 18 19 20 21 22 23 24 31 32
Press and release the Preset button to select group 2 (figure 3-33).
Press and release the Preset button to select group 2.
The button lights amber to indicate the selection.
C O N T R O L
VIEW
ENTER PRESET
Group # 1 2 3
Press and release the Input 5 through 8 and Output 5 through 8 buttons
(figure 3-34).
Press and release the Input 5 through Input 8 buttons.
The selected buttons light green.
1 2 3 4 5
17 18 19 20 21 22 23 24 25 32
Press and release the Output 5 through Output 8 buttons.
The selected buttons light green.
1 2 3 4 5
17 18 19 20 21 22 23 24 25 32
I
6 7 8 15 16
N
P
U
T
S
O
6 7 8 15 16
U
T
P
U
T
S
ESC
4
I
6 7 8 15 16
N
P
U
T
S
O
6 7 8 15 16
U
T
P
U
T
S
