ExtremeSwitching X460-G2 Series Switches

ExtremeSwitching X460-G2 Series Switches
The X460-G2 series switches provide 24 or 48 Ethernet ports that deliver high-density fast Ethernet or
Gigabit Ethernet connectivity using fixed BASE-T and BASE-X ports. In addition, some models offer
either 24 or 48 PoE+ ports.
Ports 25-48 on the X460-G2-24t-24ht-10GE4 and X460-G2-24p-24hp-10GE4 models can operate in
half-duplex mode. All other X460-G2 ports are full-duplex.
The X460-G2 series switches include the following base models:
•
ExtremeSwitching X460-G2-24t-GE4 Switch Ports and Slots
•
ExtremeSwitching X460-G2-24t-10GE4 Switch Ports and Slots
•
ExtremeSwitching X460-G2-24x-10GE4 Switch Ports and Slots
•
ExtremeSwitching X460-G2-24p-GE4 Switch Ports and Slots
•
ExtremeSwitching X460-G2-24p-10GE4 Switch Ports and Slots
•
ExtremeSwitching X460-G2-48t-GE4 Switch Ports and Slots
•
ExtremeSwitching X460-G2-48t-10GE4 Switch Ports and Slots
•
ExtremeSwitching X460-G2-24t-24ht-10GE4 Switch Ports and Slots
•
ExtremeSwitching X460-G2-48x-10GE4 Switch Ports and Slots
•
ExtremeSwitching X460-G2-48p-10GE4 Switch Ports and Slots
•
ExtremeSwitching X460-G2-24p-24hp-10GE4 Switch Ports and Slots
•
ExtremeSwitching X460-G2-16mp-32p-10GE4 Switch Ports and Slots
Each base model is available with either front-to-back or back-to-front cooling. There is no operational
difference between these switch versions.
A serial console port on the front panel of the X460-G2 series switch allows you to connect a terminal
and perform local management. An Ethernet management port can be used to connect the system to a
parallel management network for administration. Alternatively, you can use an Ethernet cable to
connect this port directly to a laptop to view and locally manage the switch configuration. The Ethernet
management port supports 10/100/1000 Mbps speeds.
Switch cooling is provided by a replaceable fan module. Fan modules are available in two different
models that direct the airflow either from front to back or from back to front. Two power supply bays
accommodate either AC or DC power supplies. Power supplies have integrated cooling fans that
operate independently of the switch fan.
Like the fan module, the power supplies are available in models with either front-to-back or back-to-
front cooling airflow. For more information about the power supplies used in the X460-G2 switches, see
Replaceable Internal Power Supplies
Power supplies and fan trays are ordered separately.
Caution
Air must flow in the same direction for all installed fan modules and power supplies in a
switch.
58 ExtremeSwitching Hardware Installation Guide
on page 130.
ExtremeSwitching Switches
on page 59
on page 60
on page 61
on page 62
on page 63
on page 64
on page 65
on page 66
on page 67
on page 69
on page 70
on page 71
