LRM/MACsec Adapter Technical Specifications

LRM/MACsec Adapter Technical Specifications
The LRM/MACsec Adapter (part no. 10965) can be attached to switch ports that are not LRM or
MACsec capable, using a cable that is specifically designed for this purpose.
Table 280: LRM/MACsec Adapter Packaged Dimensions
Height
Width
Length
Weight
Table 281: LRM/MACsec Adapter Power Specifications

LRM/MACsec Adapter Environmental Data and Standards

Table 282: Environmental Data
Operating temperature
Storage and transportation
temperature
Humidity
Altitude
Table 283: Safety Standards
North American Safety of ITE UL 62368-1:2014, Listed Device (US)
European Safety of ITE
450 ExtremeSwitching Hardware Installation Guide
3.00 cm (1.18 in)
7.60 cm (2.99 in)
12.35 cm (4.86 in)
300 g (0.66 lb)
0°C to 40°C (32°F to 104°F) when used with the following optics
modules:
• Tunable DWDM SFP+ (part no. 10325)
• ER SFP+ (part no. 10309)
• ZR SFP+ (part no. 10310)
• Bidirectional 120 km SFP (part nos. MGBIC-BX120-U and MGBIC-
BX120-D)
0°C to 45°C (32°F to 113°F) when used with all other supported optics
modules
-40°C to 70°C (-40°F to 158°F)
10% to 95% relative humidity, non-condensing
0 to 3,000 meters (9,850 feet)
UL 60950-1 2nd Ed., A2:2014, Listed Device (US)
CAN/CSA 22.2 #62368-1-14:2014 Canada)
EN 62368-1:2014
EN 60950-1:2006+A11+A1+A12+A2
IEC 62368-1:2014
IEC 60950-1:2005 2nd+A1:2009+A2:2013
2014/35/EU Low Voltage Directive
