Replacing Fan Modules

Pre-Installation Requirements

Airflow Direction Requirements

Replacing a Fan Module
For switches with replaceable fan modules, refer to the following information to replace the fan
modules.
Illustrations in this chapter show switches that might not be identical to the ones you are using.
However, the procedure for replacing a fan module is the same for all ExtremeSwitching switches.
Note
Read all of the information in this chapter thoroughly before attempting to replace a fan
module.
Pre-Installation Requirements
You need a 1/4-inch flat-blade screwdriver to replace a fan module.
Caution
Be sure to finish the replacement procedure promptly. The switch could overheat if left
without cooling for an extended period.
Airflow Direction Requirements
•
The air flows from front to back. In these switch models, the fan modules are labeled Air Out.
•
The air flows from back to front. In these switch models, the fan modules are labeled Air In.
X465 switches are available with front-to-back airflow. In this switch, the fan modules are labled Air Out.
All installed fan modules must blow air in the same direction and must match the airflow direction of
the installed power supplies.
