ExtremeSwitching X465 Series Switch LEDs
Port LEDs in Default (SYS) Mode
In the default SYS mode, SPD and STK are OFF, and the port status will display as described in
Table 19: Port LEDs in SYS Mode (default)
Color/State
Steady green
Steady amber
Blinking green
Blinking amber
Slow blinking amber
Alternating amber and green
Off
Port LEDs in SPD Mode
After one press of the Mode button (see
Mode, indicated by the SPD LED. SPD mode is used to help determine the operational speed of a port.
Color and blink pattern indicate speeds, as referenced by
Table 20: Port LEDs in SPD Mode
Color/State
Steady green
Blinking green
Solid amber
Slow blinking amber
Fast blinking amber
Slow blinking green
Fast blinking green
Fast blinking green
Port LEDs in STK Mode
After two presses of the Mode button, the port LEDs will enter the STK Display Mode, indicated by the
STK LED. STK mode is used to indicate slot presence and slot number via the first eight port LEDs, as
referenced by
Table 21: Port LEDs Indicating Stack Slot Presence in STK Mode
Port 1-8 Color/State Stacking Indication
Steady green
Blinking green
82 ExtremeSwitching Hardware Installation Guide
Meaning
Link is OK; port is not powered
Link is OK; port is powered; no traffic
Link is OK and transmitting packets; port is not powered
Link is OK and transmitting packets; port is powered
No link, or disabled port; port is powered
Port has a power fault
Port is not powered, has no link, or is disabled
Table 21:
Slot corresponding to the port number of the LED is present
This slot has a slot number corresponding to the port number of the blinking LED
Figure 82 on page 81), the port LEDs will enter the SPD Display
Table 20:
Speed
10Mbps
100Mbps
1000Mbps
2.5Gbps
5Gbps
10Gbps
25Gbps
40Gbps
ExtremeSwitching Switches
Table 19:
