To enable the 1-Port Serial Mini-Physical Interface Module (Mini-PIM) installed on the services gateway,
you must configure the basic settings for the PIM. You can perform the configuration tasks for this using
either the J-Web interface or the CLI.

Using the J-Web Interface

To perform basic configuration of the 1-Port Serial Mini-PIM and to configure network interfaces for the
services gateway using the J-Web interface:
1. In the J-Web interface, select Configure>Interfaces.
The Interfaces page displays and lists the network interfaces present on the services gateway, along
with configuration information (if configured).
2. Select the interface name (se-1/0/0) and click Add > Logical Interfaces. Enter the details and click OK.
To use the port on the Mini-PIM, assign an IP address to the port and assign it to a security zone, other
than the Null zone. If there are no security zones listed, proceed to the next step to add a security zone.
3. Add a security zone to the interface:
a. Select Configure>Security>Zones/Screens.
b. Add or select a security zone other than Null; for example, Trust. Assign the interface to the zone.
c. For Host Inbound Traffic-Zone, set the following:
System Services=Allow All
Protocols=Allow All
d. Click OK to save changes, and select Commit>Commit to apply the configuration and other pending
changes (if any).
4. To use the port on the Mini-PIM, you must also set security policies. Select the following settings:
a. Select Configure>Security>Security Policy.
b. Select Global Options > Policy Options.
c. Set Policy Action: Default Policy Action=Permit-All.
d. Click OK to save changes, and select Commit>Commit to apply the configuration and other pending
changes (if any).
