I Commands
Usage Guidelines
You must use the no switchport command in the interface configuration mode to configure the interface as
a Layer 3 routed interface. When you configure the interface as a Layer 3 interface, all Layer 2 specific
configurations on this interface are deleted.
Use the switchport command to convert a Layer 3 interface into a Layer 2 interface. When you configure the
interface as a Layer 2 interface, all Layer 3 specific configurations on this interface are deleted.
Examples
This example shows how to enter configuration mode for a Layer 3 Ethernet interface 1/5:
switch(config)# interface ethernet 1/5
switch(config-if)# no switchport
switch(config-if)# ip address 10.1.1.1/24
switch(config-if)#
This example shows how to configure a Layer 3 subinterface for Ethernet interface 1/5 in the global
configuration mode:
switch(config)# interface ethernet 1/5.2
switch(config-if)# no switchport
switch(config-subif)# ip address 10.1.1.1/24
switch(config-subif)#
This example shows how to configure a Layer 3 subinterface in interface configuration mode:
switch(config)# interface ethernet 1/5
switch(config-if)# no switchport
switch(config-if)# interface ethernet 1/5.1
switch(config-subif)# ip address 10.1.1.1/24
switch(config-subif)#
This example shows how to convert a Layer 3 interface to a Layer 2 interface:
switch(config)# interface ethernet 1/5
switch(config-if)# no switchport
switch(config-if)# ip address 10.1.1.1/24
switch(config-if)# switchport
switch(config-if)#
Related Commands
Command
bandwidth
delay
encapsulation
Description
Sets the bandwidth parameters for an interface.
Configures the interface throughput delay value.
Sets the encapsulation type for an interface.
