Pin
31
33
35
37
39
41
43
45
47
49
VI: Voltage input/VO: Voltage Output
I: Signal input/O: Signal output/GND: Reference potential (ground)
Cable specification:
● 50-pin ribbon cable connector: 50-pin insulation piercing connecting device with strain
● The required connecting cables (ribbon cables) must be provided by the user. Maximum
PPU
Manual, 03/2013, 6FC5397-2DP40-3BA1
Signal name
DO 4.0
DO 4.2
DO 4.4
DO 4.6
DO 5.0
DO 5.2
DO 5.4
DO 5.6
DOCOM3
DOCOM3
relief, ribbon cables and terminal converter are required to connect the digital inputs and
outputs.
cable length: 30 m
Type Pin Signal name
O 32 DO 4.1
O 34 DO 4.3
O 36 DO 4.5
O 38 DO 4.7
O 40 DO 5.1
O 42 DO 5.3
O 44 DO 5.5
O 46 DO 5.7
VI 48 DOCOM3
VI 50 DOCOM3
Connectable components
7.5 PP 72/48D PN
Type
O
O
O
O
O
O
O
O
VI
VI
