Chapter 8:
Readback and Configuration Verification
To read registers other than STAT, the address specified in the Type-1 packet header in Step
2 of
the FDRO register is a special case that is described in
Procedure
Configuration Memory Read Procedure (SelectMAP)
The process for reading configuration memory from the FDRO register is similar to the
process for reading from other registers. Additional steps are needed to accommodate the
configuration logic. Configuration data coming from the FDRO register passes through the
frame buffer. The first frame of readback data should be discarded.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10. Write two dummy words to the device to flush the packet buffer.
11. Read the FDRO register from the SelectMAP interface. The FDRO read length is the
12. Write one NOOP instruction.
13. Write the START command.
14. Write the RCRC command.
15. Write the DESYNC command.
16. Write at least 64 bits of NOOP commands to flush the packet buffer. Continue sending
Each of these steps is performed by a single configuration packet except for step 1 and
step 8. Synchronization (step 1) and the large FDRO read (step 8) are performed by a
Type-1, Type-2 packet combination.
102
Table 8-1
should be modified and the word count changed if necessary. Reading from
(SelectMAP).
Write the Synchronization word to the device.
Write 1 NOOP command.
Write the RCRC command to the CMD register.
Write 2 NOOP commands.
Write the Shutdown command.
Write four NOOP instructions to ensure the shutdown sequence has completed.
DONE goes Low during the shutdown sequence.
Write the RCFG command to the CMD register.
Write the Starting Frame Address to the FAR (typically 0x00000000)
Write the read FDRO register packet header to the device. The FDRO read length is
given by:
FDRO Read Length = (words per frame) x (frames to read + 1) + 1
One extra frame is read to account for the frame buffer. The frame buffer produces one
dummy frame at the beginning of the read and one at the end. Also, one extra word is
read in SelectMap8 mode.
same as in step 8 above.
CCLK pulses until DONE goes High.
www.xilinx.com
Configuration Memory Read
Table 8-2
shows the readback command sequence.
Virtex-4 FPGA Configuration User Guide
R
UG071 (v1.12) June 2, 2017
