2014 RZR XP 4 1000
ENGINE
Domestic Twin Cyl., 4–Stroke,
Platform
DOHC
Engine Displacement
999cc
Number of Cylinders
2
Bore & Stroke 93 x 73.6 mm
Compression Ratio
10.5:1
Engine Idle Speed
1200 +/- 100 RPM
Engine Max Speed
8800 RPM
Valve Clearance (Intake) 0.005-0.007" (0.125-0.175 mm)
Valve Clearance (Exhaust) 0.009-0.011" (0.229-0.275 mm)
Engine Hot Light
Instrument Cluster Indicator
Wet Sump
Lubrication
Oil Requirements
PS4
Oil Capacity 2.5 qts. (2.4 L)
Coolant Capacity 6.0 qt (5.6 L)
FUEL SYSTEM
Type Bosch ME17 EFI
Fuel Delivery Electronic Fuel Pump (in-tank)
Fuel Pressure 58 ± 2 PSI (400 ± 14 kPa)
Fuel Capacity / 9.5 gal. (36 L)
Requirement 87 Octane (minimum)
ELECTRICAL
Alternator Max Output 560 Watts @ 3000 RPM
Lights: Main Headlights Dual Beam LED cluster
Taillights 0.2 Watt LED cluster
Brake Lights 2.9 Watt LED cluster
Ignition System ME17 ECU
Spark Plug / Gap XG4YCX / 0.7–0.8 mm
Battery / Amp Hr 12v Flooded, 575 CCA
DC Outlet Standard 12 Volt
Relays Fan, EFI, Fuel Pump, Chassis,
EPS (if appl.)
Circuit Breaker 20A Cooling Fan
Fuses 20A EFI
10A Fuel Pump
5A Brake Light
20A Accessory
10A Drive
10A Lights
20A EPS (if appl.)
9924874 R02 - 2014 RZR XP / XP 4 1000 Service Manual
© Copyright 2013 Polaris Industries Inc.
GENERAL INFORMATION
DRIVETRAIN
Transmission Type
Polaris Automatic PVT
Shift Type
In Line Shift - P/ H / L / N / R
Transmission Gear Ratios:
High 10.73:1
Low 22.79:1
Reverse 20.41:1
Front Gearcase Lubricant Demand Drive
Requirement 8.5 oz. (250 ml)
Transmission Lubricant Full Synthetic AGL
Requirement 44 oz. (1300 ml)
Drive Belt 3211148
STEERING / SUSPENSION
Toe Out 1/8 - 3/16" (3.2 - 4.8 mm)
Front Suspension Independent Dual A-arm
Walker Evans™ 2.0"
Front Travel 16" (40.6 cm)
Rear Suspension Independent Trailing Arm
Walker Evans™ 2.5"
Rear Travel 18" (45.7 cm)
Spring Adjustment Threaded Spanner Wrench
Adjustment
WHEELS / BRAKES
Front Rim / Size Aluminum 14 x 6
Rear Rim / Size Aluminum 14 x 8
Maxxis Bighorn
Front Tire Make / Model /
Size 29 x 9 R14
Rear Tire Make / Model / Maxxis Bighorn
Size 29 x 11 R14
Front 19 psi (131 kPa)
Tire Air Pressure
Rear 20 psi (138 kPa)
Brake System Foot Actuated 4 Wheel
Front & Rear Hydraulic – Dual Bore Caliper
Brake Fluid DOT 4
2014 RZR XP / XP 4 1000 Clutch Charts, page 1.10
