Unlocking the TMA 1600-III.

To unlock the TMA 1600-III, follow
the steps below:
1. Remove the yellow "Step 3"
sticker from the TMA 1600-III.
2. Look for the locking knob at the
base of the TMA 1600-III.
3. Turn the locking knob
counterclockwise to the unlock
position " ".
Shipping the TMA 1600-III
If you have to transport the TMA 1600-III, you will need to lock the TMA 1600-III
back. Follow the steps below:
1. Make sure the TMA 1600-III is
connected to the scanner, then
turn off the scanner if your
scanner is on.
2. Turn the scanner back on. The
TMA 1600-III's carriage will move
to the standby position in a few
moments.
3. When the indicators on the front
of your TMA 1600-III and scanner
stop blinking, turn the locking
knob clockwise to the lock
position " ".
4. Turn off your scanner and disconnect the TMA 1600-III connector from the
scanner. The TMA 1600-III is ready for transport.
ArtixScan 3200XL User Guide 9
