Lamp Replacement Instructions
A scanner is a precision optical instrument and changing a lamp is not like changing a
household bulb. We do not recommend that you replace the scanner lamp on your own
because of potential problems that may come up during the lamp replacement. Technical
Support personnel are not trained in repair; therefore, if you get in trouble, assistance in
replacing the lamp is not available. Proceed at your own risk!
Tools Needed:
Phillips Screw Driver
Flat Screw Driver or small pry bar
Needle Nose Pliers
Recommended Materials:
Glass Cleaning Cloth
Canned Air
Selecting A Work Area
It is important that you begin by planning where you will lay your disassembled parts.
Locate an area with a workbench, table or desk with plenty of space.
Make sure that the area is clear of any other parts from other devices, as the many
screws and nuts can be easily confused.
We recommend that you lay a sheet or tablecloth on the surface you will be
working on. This will prevent tools, parts and screws from sliding around and
falling to the floor. This will also prevent any parts from scratching the surface of
the work area.
ScanMaker 3700
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ScanMaker 3700 and is the answer not in the manual?

Questions and answers

Related Manuals for Microtek ScanMaker 3700

Summary of Contents for Microtek ScanMaker 3700

  • Page 1 Lamp Replacement Instructions ScanMaker 3700 A scanner is a precision optical instrument and changing a lamp is not like changing a household bulb. We do not recommend that you replace the scanner lamp on your own because of potential problems that may come up during the lamp replacement. Technical Support personnel are not trained in repair;...
