User Manual
Start Here
Installing your Microtek ArtixScan 3200XL
Step 1:
Unpack your scanner package and
check for major components.
1. ArtixScan 3200XL (lower base)
2. USB Cable
3. Power Cord
4. Software CDs/DVDs
5. TMA 1600-III
6. Black Plate
7. U-shaped Ruler (Calibration Ruler
8. 4" x 5" Film Template
9. 120 Film Template with Black Plate
10. 35mm Slide Template
11. 35mm Filmstrip Template
Step 2:
Important: Do not remove the yellow stickers from your scanner
until you are told to do so.
You must install software before connecting your scanner.
close any open programs, and turn off Anti-virus utilities before
installing software.
PC:
A.
Place the Adobe DVD into a drive, and install
the software. Skip this step if you have a
newer version of Photoshop Elements already
installed on your computer.
B.
Place the Microtek Software CD/DVD into a
drive, and follow the on-screen instructions to
install the driver and software.
NOTE: If the Microtek Software Installer screen does not
come up automatically, double-click the following in
succession: "My Computer"; the CD/DVD-ROM icon; then
cdsetup.exe to start the installer program.
C.
Restart your computer at the end of all
software installation.
Copyright © 2013
Microtek International, Inc.
I49-004647 C, September 2013
Unpack Contents
1
2
Install Software
Always
http://www.microtek.com
5
6
4
3
MAC:
A.
Place the Adobe DVD into a drive, and install
the software. Skip this step if you have a
newer version of Photoshop Elements already
installed on your computer.
B.
Place the Microtek Software CD/DVD into a
drive, and double-click the ScanWizard Pro
installer icon to install ScanWizard Pro first.
C.
Install the remaining software components,
then restart your computer at the end of all
software installation.
NOTE: After rebooting your Macintosh, the Microtek software
will attempt to locate your scanner on the system. Since this is
your first install and you have not yet connected the scanner,
simply ignore the message that appears and proceed to the next
step.
1
8
9
10
11
7
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Microtek ArtixScan 3200XL
Summary of Contents for Microtek ArtixScan 3200XL
- Page 1 ScanWizard Pro install the driver and software. installer icon to install ScanWizard Pro first. NOTE: If the Microtek Software Installer screen does not Install the remaining software components, come up automatically, double-click the following in then restart your computer at the end of all succession: “My Computer”;...
-
Page 2: Unlock Scanner
NOTE: To lock the scanner (for shipping and other reasons), refer to “ArtixScan 3200XL User Guide” in your Microtek Software CD/DVD. Step 4: Connect Scanner... - Page 3 Turn the locking knob counterclockwise to the unlock position “ ”. NOTE: If you need to transport your TMA 1600-III, you will have to lock it back. For more details, refer to “ArtixScan 3200XL User Guide” in your Microtek Software CD/DVD.
- Page 4 U-shaped Ruler make sure you use the (Calibration Ruler) correct side up. The correct side up is the side showing the “Microtek” logo facing up. Calibration strip (Keep clear and unobstructed) Using the 35mm Slide Template Using the 35mm Filmstrip Template Using the 120 Film Template Using the 4”...
- Page 5 TMA 1600-III, you will need to use the Black Plate (Keep clear and included in your scanner package to shield unwanted unobstructed) light. NOTE: For more details on positioning the transparencies and reflectives on the scanner glass surface, refer to “ArtixScan 3200XL User Guide” in your Microtek Software CD/DVD.
-
Page 6: Calibrating Your Scanner
If you update the firmware to a new version, you have to re-calibrate your scanner. For more details, refer to the “ArtixScan 3200XL User Guide” in your Microtek Software CD/DVD and see the Calibrating Your Scanner section. Notice to WIA Users Before using the WIA (Windows Image Acquisition) scanning driver to scan, you should put the U-shaped Ruler on the scanner glass surface, which ensures that your scanner will function properly. -
Page 7: Your First Scan
OK for now to accept the settings. You can always change the settings at a later time. For more details, refer Smart-Touch button to “ArtixScan 3200XL User Guide” in your Microtek Software CD/ (Scan) DVD. Position the photo face down on the scanner glass surface toward the front of the scanner, as detailed in the “Positioning Reflectives”... -
Page 8: Scanning Photos
Scanning Photos Position the photo face down on the scanner glass surface Calibration strip toward the front of the scanner, as detailed in the (Keep clear and “Positioning Reflectives” section in this guide. unobstructed) Launch ScanWizard Pro. In the Preview window of ScanWizard Pro, choose Reflective from the Scan Material menu. - Page 9 Go to the Negative Scan Settings window, choose the film brand, film type, and ISO settings that match the film you use. For more details, refer to “ScanWizard Pro Reference Manual” in your Microtek Software CD/DVD and see the Addendum to ScanWizard Pro section. Follow steps 4 to 7 of the procedures detailed in “Scanning Photos”.
- Page 10 Calibration The Microtek Scanner ICC Profiler (MSP) program included with your ArtixScan 3200XL is used to calibrate your scanner to achieve consistent and accurate color. Two optional industry-standard IT8 color targets are Reflective target for calibration: a Reflective target to calibrate the upper scan bed for scanning photos;...
- Page 11 After you finish the installation of software, if you found that the installed drivers and software cannot run your product or your computer system properly later, please go to the Microtek Download Service site at ww7.microtek.com.tw/service.php to download and install any updates you may require.
