Start Here
I nstalling your Microtek ArtixScan DI 6260S/6250S/6240S &
ArtixScan TS 630S
Unpack Contents
Unpack your scanner package and check for
major components.
1. Scanner
2. Hi-Speed USB cable
3. Software CDs/DVDs
4. Power cord
5. Power adapter

Install Software

Important:
You must install software before connecting
your scanner. Always close any open programs, and
turn off Anti-virus utilities before installing software.
PC:
A. Place the Microtek Software CD/DVD
into a drive, and follow the on-screen
instructions to install the scanner
driver and software.
B. Restart your computer at the end of all
software installation.
NOTE: If the Microtek Software Installer screen
does not come up automatically, double-click the
following in succession: "My Computer"; the CD/
DVD-ROM icon; then cdsetup.exe to start the
installer program.
Copyright © 2013
Microtek International, Inc.
I49-004856 D, September 2013
1
2
MAC:
A. Place the Microtek Software CD/DVD
(ScanPotter) into a drive, and double-click
the ScanPotter installer icon to install
ScanPotter.
B. Install the remaining software
components, then restart your computer
at the end of all software installation.
NOTE: After rebooting your Macintosh, the Microtek
software will attempt to locate your scanner on the
system. Since this is your first install and you have
not yet connected the scanner, simply ignore the
message that appears and proceed to the next step.
1
http://www.microtek.com
5
4
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ArtixScan DI 6260S and is the answer not in the manual?

Questions and answers

Related Manuals for Microtek ArtixScan DI 6260S

Summary of Contents for Microtek ArtixScan DI 6260S

  • Page 1: Install Software

    Start Here I nstalling your Microtek ArtixScan DI 6260S/6250S/6240S & ArtixScan TS 630S Unpack Contents Unpack your scanner package and check for major components. 1. Scanner 2. Hi-Speed USB cable 3. Software CDs/DVDs 4. Power cord 5. Power adapter Install Software...
  • Page 2 Open Feed Tray & Output Tray B. Along the tracks of the two sides of the Open Feed Tray Document Feed Tray, slide the feed tray A. Lift up the Document Feed Tray to the down until the supporters of the tray highest level which can be opened.

  • Page 3: Connect Scanner

    Connect Scanner To the power adapter A. Connect the power adapter to the back of the scanner. B. Plug one end of the power cord into the power adapter, and plug the other end of the power cord into a wall outlet or other power source. To the Hi-Speed USB cable C.

  • Page 4: To Load A Stack Of Documents

    WARNING: The document feeder is not designed for scanning photos; doing so may damage your originals. Microtek accepts no responsibility for damage that may arise from misuse of equipment. 3. Align the stack of originals with the...

  • Page 5: To Load Cards

    To Load Cards 1. Slide the Guide Arms toward the center of the feed tray and free up the enough space to put the card inside. 2. Load and center the card onto the scanner’s Document Feed Tray, with the front side facing up and the top edge directing toward the feeder.
  • Page 6 Basic Scanning for PC Users 1. Load the stack of documents to be scanned onto the ADF’s Document Feed Tray. WARNING: Do not place photo paper or fragile sheets of paper on the feed tray, as doing this will damage the original photo or frail papers during the feeding process. 2.
  • Page 7 “Main”) Image type Image correction settings Preview image (the enclosed frame bordered in red) Preview window NOTE: For more details on other scanning scenarios applicable to your scanner, refer to the scanner’s User’s Manual in the Microtek Software CD/DVD.
  • Page 8 9. Click the Scan button to start scanning. NOTE: For more details on using ScanPotter, refer to the ScanPotter Reference Manual in the Microtek Software CD/DVD.
  • Page 9 Click the Scan Settings button to switch back to the default control panel of ScanPotter Click the Image Settings button to switch to a window where contains a composite display of image-effects (Filter column) and additional image correction tools (Additional Adjustment column) for your scanned image.

  • Page 10: Fixing Paper Jams

    Fixing Paper Jams Release button 1. Lift up the Release button in the direction of arrow shown to open the scanner cover. Scanner cover 2. Remove the jammed paper by taking out it in an upward direction. 3. Close the scanner cover. You should hear a click sound when the scanner cover returns to its original position.

  • Page 11: Care And Cleaning

    The recommended cleaning cycle time would be after approximately 3,000 to 5,000 scans. • For more details on cleaning, refer to the scanner’s User’s Manual in the Microtek Software CD/DVD and see the “Care and Cleaning” section on pages 44 to 47.

  • Page 12: Maintenance

    Feed Roller Assembly is around 100,000 scans. • Please contact your local resellers for purchasing new rollers. • For more details of replacement, refer to the scanner’s User’s Manual in the Microtek Software CD/DVD and see the “Maintenance” section on pages 48 to 52.
  • Page 13 Problems? The green LED lighting (the SCAN/STOP button) indicates the status of the scanner. The orange LED lighting (the POWER button) stands for power and should always stay on steady when the scanner is on. Orange LED All On: Ready to scan. Green LED Flashing Green: Scanning.
  • Page 14 After you finish the installation of software, if you found that the installed drivers and software cannot run your product or your computer system properly later, please go to the Microtek Download Service site at ww7.microtek.com.tw/service.php to download and install any updates you may require.
