KIT CONTENTS: We have organized the parts as they come out of the box for better identification
during assembly. We recommend that you regroup the parts in the same manner. This will ensure you
have all of parts required before you begin assembly.
MAIN GEAR ASSEMBLY
(2) Main gear aluminum
(2) 65mm diameter wheel
(2) Fiberglass wheel pant
(4) 4mm x 20mm socket head screw
(4) 8mm flat washer
(4) 16mm flat washer
(4) 4,5mm nut
(4) Collar
(4) 3mm x 4mm set screw
(2) 4mm x 58mm axle
(4) 4mm lock washer
TAIL WHEEL ASSEMBLY
(1) Tail wheel bracket w/wire
(1) 25mm diameter wheel
(2) 2mm collar
(2) Nylon control clasp
(2) 2mm x 16mm wood screw
ELEVATOR CONTROL SYSTEM
(1) 3mm x 150mm metal pushrod
(1) 3mm x 85mm metal pushrod
(2) M3 clevis
(2) 3mm x 40mm screw
(2) Set aluminum control horn
(2) Nylon horn
(2) Nylon ball link
(2) Aluminum ball
(2) 3mm x 12mm screw
(2) 6mm flat washer
(2) 3mm nut

KIT CONTENTS

RUDDER CONTROL SYSTEM
(1) 3mm x 165mm metal pushrod
(1) M3 Clevis
(1) 3mm x 40mm screw
(1) Set aluminum control horn
(1) Nylon horn
(1) Nylon ball link
(1) Aluminum ball
(1) 3mm x 12mm screw
(1) 6mm flat washer
(1) 3mm nut
AILERON CONTROL SYSTEM
(2) 3mm x 70mm metal pushrod
(2) M3 Clevis
(2) 3mm x 45mm screw
(2) Set aluminum control horn
(2) Nylon horn
(2) Nylon ball link
(2) Aluminum ball
(2) 3mm x 12mm screw
(2) 6mm flat washer
(2) 3mm nut
MOTOR MOUNT ASSEMBLY
(4) 4mm x 25mm screw
(4) 4mm lock washer
(4) 8mm flat washer
(4) 4mm x 30mm screw
(8) 4mm nut
(4) 4mm lock washer
(2) Engine mount
1
CAP 232
THROTTLE CONTROL SYSTEM
(1) 1,3mm x 500mm wire
(1) 3,5mm x 350mm nylon
pushrod housing
(1) Metal connector
(1) 4mm x 4mm machine screw
FUEL TANK
(1) Nylon fuel tank
(1) Metal clunk
(1) Pre - assembled stopper w / 3 tube
MISCELLANEOUS ITEMS
(1) 19mm x 270mm diameter
aluminum dihedral
(2) 6mm x 45mm nylon screw
(2) Nylon washer
(1) Spinner
(4) 2.6mm x 10mm wood screw
(1) 25mm x 400mm orange tape
(1) 25mm x 400mm blue tape
