Table A.10: MSATA1: MSATA
12 NC
13 NC
14 NC
15 GND
16 NC
17 NC
18 GND
19 NC
20 NC
21 GND
22 NC
23 SATA1_RX+
24 +3.3 V
25 SATA1_RX-
26 GND
27 GND
28 NC
29 GND
30 NC
31 SATA1_TX-
32 NC
33 SATA1_TX+
34 GND
35 GND
36 NC
37 GND
38 NC
39 +3.3 V
40 GND
41 +3.3 V
42 NC
43 NC
44 NC
45 NC
45 NC
47 NC
48 NC
49 NC
50 GND
51 +3.3 V
52 +3.3 V
