4.1.2 Jumpers and Connectors

The UTC-318 motherboard features several jumpers and connectors that enable
users to configure the system according to the applications. The function of every
motherboard jumper is listed in the table below.
Table 4.1: Jumper and Connector Functions
Label
CN1
CN3
CN4
CN6
CN7
CN8
CN9
CN13
MINIPCIE1
MSATA1
CN16
CN18
CN22
CN21
CN23
CN24
CN25
CN26
CN27
CN28
CN30
CN31
SW2 BUTTON
Function
Back_Light
Internal USB
LVDS
SATA
SATA Power
Internal USB
Touch
DDR3L SODIMM
MiniPCIe
mSATA
COM2
COM1
Speaker
Power switch
LAN1/LAN2
External USB
External USB
External USB
Line-out
Mic-in
HDMI
DC-in
Power button
