Page 1: User Manual
USER MANUAL WMF 1000 COFFEE MACHINE ENGLISH 0.40 WMF1000 33 0915 6010 2006.08... - Page 2 You will be impressed by the machine‘s technical design, its long service life and economical operation, and especially by the quality of the coffee it produces. The WMF 1000 pro coffee machine is a fully-automatic single-cup coffee machine for espresso, café crème, cappuccino, café latte, latte macchiato, hot milk, foamed milk and hot water.
-
Page 3: Table Of Contents
Insert the WMF tank filter ........11... - Page 4 Cleaning the bean hopper ........45 Chapter 7 HACCP cleaning schedule WMF 1000 user manual...
- Page 5 Service/maintenance/repair in the WMF 1000 Service-Center ..58 Return delivery ticket WMF 1000 ......58...
-
Page 6: Chapter 1 Introduction And General Information
Introduction and General Information Chapter 1 Introduction and General Information 1.1 Parts of the machine WMF 1000 user manual... - Page 7 Milk button / Milk foam button Beverage buttons Milk lever (conversion milk/milk foam) Height-adjustable all-in-one spout with integrated milk foamer Adjustment lever for all-in-one spout Water tank Removable drip tray with drip tray grid Coffee grounds container WMF 1000 user manual...
-
Page 8: Overview Of Control Buttons
Read this user manual before starting to prepare coffee. Only then can you operate all functions and the machine safely and spoil yourself with a wonderful coffee beverage. Additional components of the user manual: • Brief manual for beverage dispensing/care WMF 1000 user manual... -
Page 9: User Manual Signs And Symbols
Risk to user Attention! Attention! Hot liquid Hot surface Attention! Attention! Danger of electric shock Danger of hand injuries Tips and hints Hint Cross-reference Note about the figure Please always heed the safety instructions in Chapter 9. WMF 1000 user manual... -
Page 10: Displaying The Readiness State
Prior to the brewing cycle, coffee is briefly infused to ensure a more intensive release of its aromatic substances. Press Automatic pressing of coffee grounds prior to brewing cycle. Range For example: litre capacity of the tank filter Rinsing Intermediate cleansing WMF 1000 user manual... -
Page 11: Chapter 2 Commissioning
first. Insert the WMF tank filter Fill water tank with drinking The WMF tank filter ensures the best coffee quality and water protects the coffee machine against calcification. With water hardness 0-4, do not use a tank filter. -
Page 12: Assembling The Milk Hose
Fill the water tank with cold tap water (max. 2.8 litres) Slide the water tank back into the machine Fill the water tank only with fresh, cold water. Never use hot water, mineral water, milk or other liquids. WMF 1000 user manual... -
Page 13: Connecting The Milk Hose To The Milk
OK: P change: -/+ OK: P change: -/+ Set the desired language for the display guidance here. The commissioning program uses the display to lead you step by step through the commissioning. Follow the display texts. WMF 1000 user manual... -
Page 14: Basic Settings
The display goes out after 5 initial setting up initial setting up seconds. of your WMF 1000 of your WMF 1000 The set values can be changed The machine is switched on, the commissioning program in the “Settings” program after commissioning. -
Page 15: Tank Filter
Your selection pls Your selection pls see Chapter 4 Settings 24.10.2006 24.10.2006 08:15 08:15 Select Confirm Care button Browse backwards – Reduce value Browse forwards Increase value The new values are saved when you exit the program. WMF 1000 user manual... -
Page 16: Chapter 3 Operation
The lighting system helps you with navigation. Only the buttons which can be operated in the current situation are lighted. 3.2 Preparation of coffee beverages The WMF 1000 has four beverage buttons, each of which has two functions. Overview of beverage buttons •... -
Page 17: Example: Preparing Café Crème
Before preparing café latte: Care button 1x café latte 1x café latte Browse backwards milk lever down milk lever down – Reduce value Browse forwards Increase value The new values are saved when you exit the program. WMF 1000 user manual... -
Page 18: Setting Coffee Strength For The Next Beverage
Set the desired coffee strength with the buttons Select the beverage The beverage button selected lights up and the beverage name is indicated on the display. The selected beverage is prepared. See preparing beverage WMF 1000 user manual... -
Page 19: Coffee Preparation Using The Manual Insert
Each brewing cycle via the manual insert is measured See Chapter 6 See Chapter 6 separately. Customer Care Customer Care • Coffee ground too fine can cause faults. > Cleaning the brewing uni > Cleaning the brewing uni WMF 1000 user manual... -
Page 20: Dispensing Milk And Milk Foam
Operation 3.3 Dispense milk and milk foam At the touch of a button, the WMF 1000 dispenses hot milk and milk foam. press short press and hold 1 cup milk Milk/milk foam on request Milk/milk foam is dispensed as long as the button is pressed. -
Page 21: Dispensing Hot Water
Never touch the spouts during or directly after dispensing beverages! • Never touch the beverages, rinse and cleaning water or steam during or directly after beverage dispensing! 3.6 Cancel beverage dispensing You can cancel the current beverage dispensing. Press the Off/C button WMF 1000 user manual... -
Page 22: All-In-One Spout
Put the all-in-one spout in a beverage dispensing position As soon as the all-in-one spout is back in a beverage dispensing position, the message disappears and the readiness display appears. WMF 1000 user manual... -
Page 23: Switching On And Off
Empty the drip tray regularly, the rinse water will be emptied into the drip tray by the all-in-one spout (approx. 200 ml). You can place a container under the all-in-one spout and catch the rinse water. WMF 1000 user manual... -
Page 24: Switching Coffee Machineon And Off In Timer Operation
In timer operation, the machine switches on again imme- diately before the automatic set time. Manual switch-off for timer operation Press the Off/C button for approx. 2 seconds The machine switches off and the timer is no longer active. WMF 1000 user manual... -
Page 25: Chapter 4 Setting
92°C OK: P change: -/+ Select factory sett.: no Confirm OK: P change: -/+ Care button Browse backwards – Reduce value Browse forwards Increase value The new values are saved when you exit the program. WMF 1000 user manual... -
Page 26: Cup Size (Cup Volumes)
Each setting can be tested during setting. 4.2 Beverage settings • Water volume • Coffee strength • *Milk volume • *Sequence of the dispensing of milk and coffee • Pre brew (aroma development) *Menu elements only available for beverages with milk WMF 1000 user manual... -
Page 27: Dispensing Test
25 sec. OK: P change: -/+ OK: P change: -/+ The volume dispensed depends on the milk lever posi- tion, the milk temperature and the milk nozzle selected. Determine the desired volume with a dispensing test. WMF 1000 user manual... -
Page 28: Sequence Of The Dispensing Of Milk And Coffee
Set water quantity Page 27 Dispensing test Test: Each setting can be tested during setting. Select Confirm Care button Browse backwards – Reduce value Browse forwards Increase value The new values are saved when you exit the program. WMF 1000 user manual... -
Page 29: Basic Settings
Here you can set how many minutes after the last at the set switch-on time. beverage preparation the coffee machine should switch off automatically. Switch-off time 0 min -> Switch-off time deactivated. WMF 1000 user manual... -
Page 30: Brewing Temperature
Off/C button has been pressed, the message appears: reset all counters reset all counters No: - No: - Yes: + Yes: + Keep the counters: press the minus button Delete all counters: press the plus button WMF 1000 user manual... -
Page 31: Chapter 5 Other Settings
Correct setting: Check your setting by preparing a double shot of espresso. If the dispensing stream is interrupted here or if the display indicates a flow fault, set the grinding degree at least one turn coarser again. WMF 1000 user manual... -
Page 32: Chapter 6 Care
Care Chapter 6 Care The care of your WMF 1000 is especially important. The display notifies you as soon as the WMF 1000 must be rinsed, cleaned or descaled. 6.1 Care program, general When switching the machine on and off, an automatic coffee system rinse starts automatically. -
Page 33: Overview Of Customer Care
Housing Water tank Ground coffee hopper WMF assumes no liability for damage due to lack of cleaning or descaling or due to the use of other cleaning or descaling agents than those provided by WMF. All guarantee and warranty claims are extinguished. -
Page 34: Calling Customer Care Programs
The pipes of the coffee machine are rinsed with hot water. Hot rinse water is emptied through the all-in-one spout. After the rinse, the readiness state display appears. your selection pls your selection pls 08:15 08:15 14.04.2006 14.04.2006 WMF 1000 user manual... -
Page 35: Rinse Milksystem
Hot rinse water is emptied through the all-in-one spout. After a successful rinse, the following display appears: lower spout lower spout into beverage position into beverage position Turn the milk hose anticlockwise, disconnecting it from the hot water spout WMF 1000 user manual... -
Page 36: Cleaning The Machine - Cleaning Program
Duration of cleaning program approx. 5 minutes. refill water tank refill water tank place 3l container place 3l container under coffee outlet under coffee outlet Place an appropriate container (min. 3 litres) under the all-in-one spout WMF 1000 user manual... - Page 37 Off/C button. Cleaning must take place within the next 50 brew cycles, however at the latest on the next day. Otherwise, beverage dispensing will be blocked. The blocking will be cleared after a cleaning. WMF 1000 user manual...
-
Page 38: Change Tank Filter
14.04.2006 Depending on the water hardness and the water flow, but after 3 months at the latest, the request appears to change the tank filter. The filter change can be put off with the Off/C button. WMF 1000 user manual... -
Page 39: Descaling
Pull the water tank out of the machine towards the front Remove the filter cartridge if a tank filter is used (important) Empty a whole bottle of WMF liquid descaling agent (750 ml) into the water tank Fill the water tank with water Place container underneath... -
Page 40: Manual Cleaning
The water hardness, the water flow and whether a tank filter is used determine the schedule for descaling. The time will be calculated by the WMF 1000 and the request will appear. The descaling can be put off with the Off/C button, however it must be carried out within the next 50 brew cycles. -
Page 41: Cleaning The Milk System
[4] [5] [6] Taking apart the all-in-one spout WMF special cleaner for milk Mix 5 ml WMF special cleaner for milk foamers in a foamers container with 200 ml lukewarm water Order no. 33.0683.6000 Place all parts of the milk system... - Page 42 Reassemble all parts of the all-in-one spout Place the milk hose on the all-in-one spout [10] Replace the all-in-one spout and push it into the lowest beverage position [11] [12] Insert the milk hose in the guide [13] [14] [15] WMF 1000 user manual...
-
Page 43: Cleaning The Brewing Unit
Use the multitool from the accessories. Unscrew the thread on the brewing unit head with the multitool anticlockwise until the scraper folds out forwards Tip the insertion unit approx. 45 degrees upwards multitool until the brewing filter is visible WMF 1000 user manual... - Page 44 Close the side doors If the brewing unit cannot be inserted completely: Turn thread on the brewing unit head slightly to the left or right with the multitool until the brewing unit slides into the guide. Never use force! WMF 1000 user manual...
-
Page 45: Cleaning In General
Check smooth running of the float (red plastic part) in the guide Replace the water tank Heavy calcium deposits can be removed with the WMF descaling agent. After descaling, rinse the water tank very thoroughly in order to remove all the descaling debris. - Page 46 With correct installation, service, care and cleaning WMF coffee machines meet the abovementioned require- ments. If the care and cleaning of the coffee machine is not carried out properly, the dispensing of milk bever- ages becomes a hazard with respect to food hygiene.
-
Page 47: Haccp Cleaning Schedule
• If a pre-refrigerated, freshly-opened milk package approx. 20 cappuccinos. is consumed within 3 hours maximum, refrigeration WMF AG offers various cooling during operation may not be necessary. possibilities • If milk consumption is lower, then the pre-refrigerated milk must be cooled during operation. -
Page 48: Chapter 8 Messages And Tips
Grinding is interrupted Pour coffee beans into the bean hopper Press the beverage button again The grinding process continues and the additional coffee required for the brewing cycle is ground The selected beverage is then brewed. WMF 1000 user manual... -
Page 49: Insert Coff. Grounds
Close the right-hand side door Close lock completely Lower spout The all-in-one spout is in the milk lower spout into system rinse position beverage position Push the all-in-one spout further down- wards into a beverage position WMF 1000 user manual... -
Page 50: Error Messages And Faults
Search in the error list for the error message and follow the instructions. If this is not successful or the error displayed is not listed, please call the WMF service hotline! Some messages lead to blocking of individual functions. You will notice this by the fact that the beverage button light goes out. - Page 51 EEPROM Error Switch machine on/off If the error repeats, the fault must be eliminated by the WMF 1000 Service-Center. See chapter WMF 1000 Service-Center Motor driver error Switch machine on/off If the error repeats, the fault must be eliminated by the WMF 1000 Service-Center.
-
Page 52: Problems With No Fault Display
Milk lever is not all the way up for milk foam or not all the way down for milk All-in-one spout: Lightly smear o-rings with WMF sealing grease and Assembly/disassembly make sure that no grease gets into the air intake... - Page 53 Brewing unit is not in the basic setting longer be pulled out or Close the right side door and switch machine on inserted The brewing unit can be adjusted using the multitool until the brewer can be inserted WMF 1000 user manual...
-
Page 54: Chapter 9 Safety
Messages and tips Chapter 9 Safety 9.1 Hazards for the user At WMF, safety is one of the most important product features. The effectiveness of safety devices is only warranted if the following points are observed: • Read the user manual carefully before use •... -
Page 55: Hazards For The Coffee Machine
• With water with a carbonate hardness in excess of 5°dKH a WMF tank filter should be used; otherwise the coffee machine can be damaged due to build-up of scale. •... -
Page 56: Responsibilities Of The Operator
For countries outside the EC, the respectively-valid national rules apply. The operator of such equipment must ensure regular servicing by WMF Customer Service technicians, their agents or other authorised persons and check the safety devices. The operator must ensure that the electrical equipment and operating facilities are in a fit state (e.g. -
Page 57: No Warranty Is Provided
Safety WMF shall always have the opportunity to rectify faults within an appropriate period. Claims above and beyond these, especially damage claims as a result of consequential damage, are - to the extent that is Warranty period 12 months legally permissible - excluded. -
Page 58: Chapter 10 Service And Maintenance
This procedure applies only in Germany. Do you have a question about the operation or function If the location of the WMF 1000 of your WMF 1000 ? Call our WMF service hotline or send is outside of Germany, please us an e-mail. -
Page 59: Technical Data
200 mm space on the right side of the machine for brewer disassembly. Weight empty approx. 19.0 kg Weight of brewer 1.2 kg Cable length approx. 1.0 m Item number 03 0500 0001 Manufacturer WMF Group WMF 1000 user manual... -
Page 60: Accessories And Spare Parts
Water filter 200 33 2332 2000 1 piece Adapter for water filter 33 2332 0000 Order numbers for the WMF customer care program 1 pack Cleaning tablets (blister 3x10 pieces) 33 2306 2000 1 bottle Milk foam cleaner (1 litre) - Page 61 33 2356 6010 • Installation manual • User manual • Brief manual daily cleaning WMF 1000 • Return delivery ticket WMF 1000 • WMF carbonate hardness test (with manual) Cleaning agents, cleaning solutions and descaling agents are irritants for people, textiles and for the plastic parts of the machine.
-
Page 62: Wmf 1000 User Manual
Beverage settings 26 Hot water button 21 Brewing temperature 30 Browse 8 Browse forwards with plus 8 Insert the WMF tank filter 11 Introduction to settings 8 Call customer care programs 33 Cancel beverage preparation 21 Care program, general 32... - Page 63 Safety systems 54 Scope of delivery 60 Second type of coffee 19 Sequence milk and coffee 28 Warm-up rinse 34 Service ticket WMF 1000 58 Warranty period 57 Set the grinding degree 31 Water filter 60 Setting 25 Water hardness 14...
- Page 64 Your nearest WMF Customer Service Centre: © 2006 WMF Aktiengesellschaft Coffee Machines Division Postfach 1401, D-73309 Geislingen/Steige, Germany. All rights reserved, in particular duplication, distribution and translation rights. No part of this Manual may be reproduced in any form or processed, duplicated or distributed using electronic systems without written consent.
