Chapter I. Chelsio Unified Wire
wtp
Description: Traces the Ingress and Egress path of a packet through the Chelsio adapter.
Syntax: cxgbtool [vbdInterface] wtp
Example:
C:\Users\Administrator>cxgbtool vbd0 wtp
LOW 0x00000000
HIGH 0x00aa0000
LOW 0x0003f000
HIGH 0x00660022
LOW 0x00000000
HIGH 0x0000eeee
LOW 0x00000000
HIGH 0x0000eeee
LOW 0x00000000
HIGH 0x00aa00aa
LOW 0x0070000b
HIGH 0x0000eeee
LOW 0x00000008
HIGH 0x0000eeee
LOW 0x00000013
HIGH 0x00550033
LOW 0x00000016
HIGH 0x0002006e
LOW 0x0000000b
HIGH 0x00880022
LOW 0x00c00001
HIGH 0x00000000
LOW 0x00000001
HIGH 0x00000000
LOW 0x00000000
HIGH 0x00000000
LOW 0x00000000
HIGH 0x00000000
LOW 0x01534745
HIGH 0x45475301
LOW 0xfeacb8ba
HIGH 0xbab8acfe
ifaces = nic0 nic1
*************************EGGRESS (TX) PATH *********************************
MOD : core---->PCIE---->SGE<-|
SOP ?
EOP ?
MOD |<-core<----PCIE<----SGE<-|
SOP | 1fe
EOP | ?
MOD |->core---->PCIE---->SGE------>CIM/uP->| #Work Request to uP
