Chelsio T5 Installation And User Manual page 179

Chapter V. Unified Wire Manager (UM)
8.8.2. Traffic Management (Linux)
Using this page, one can add/delete/modify offload policies only in the presence of offload driver
(t3_tom for T3 adapters; t4_tom for T4 adapters).
8.8.3. Traffic Management configuration
The Chelsio Card section on the left displays all the cards available in the server and their
corresponding policies on the right. Policies can be added and deleted. Policy Details displays
the primitives (maximum 8) and actions which can be modified. For more details on creating
policies, please refer to COP man pages.
Figure 8.8.3 - Traffic Management Configuration module
Chelsio T5/T4 Unified Wire for Windows 179
