Chapter I. Chelsio Unified Wire
tpi
Description: Displays TP indirect registers.
Syntax: cxgbtool [vbdInterface] tpi
Example:
C:\Users\Administrator>cxgbtool vbd0 tpi
TP_PIO
[ 0x20] TP_RX_SCHED_MAP
31:24 S_RXMAPCHANNEL3
23:16 S_RXMAPCHANNEL2
15:8 S_RXMAPCHANNEL1
7:0 S_RXMAPCHANNEL0
[ 0x21] TP_RX_SCHED_SGE
15:12 S_RXSGEMOD1
11:8 S_RXSGEMOD0
3:3 S_RXSGECHANNEL3
.
.
.
sgedbg
Description: Displays sge debug indirect registers.
Syntax: cxgbtool [vbdInterface] sgedbg
Example:
C:\Users\Administrator>cxgbtool vbd0 sgedbg
SGE_DEBUG_DATA_HIGH00
SGE_DEBUG_DATA_HIGH01
SGE_DEBUG_DATA_HIGH02
SGE_DEBUG_DATA_HIGH03
SGE_DEBUG_DATA_HIGH04
SGE_DEBUG_DATA_HIGH05
SGE_DEBUG_DATA_HIGH06
SGE_DEBUG_DATA_HIGH07
SGE_DEBUG_DATA_HIGH08
SGE_DEBUG_DATA_HIGH09
SGE_DEBUG_DATA_HIGH10
SGE_DEBUG_DATA_HIGH11
.
.
.
Chelsio T5/T4 Unified Wire for Windows
0x55555555 1431655765
0x55 85
0x55 85
0x55 85
0x55 85
0xf 15
0 0
0 0
0x1 1
0x3000000 50331648
0 0
0 0
0 0
0 0
0 0
0 0
0 0
0x26020000 637665280
0 0
0x3 3
0 0
