CHAPTER 9 SETTING UP CELLULAR FEATURES
Field
Acknowledgment String to Caller
Init String Number

Using Telnet to communicate with the cellular radio

Your router comes with an integrated cellular radio. You can use this cellular radio directly without using any
router functions. To do so, you must use redirector software on your computer. This software creates a virtual
serial port that allows your computer to communicate with the integrated cellular radio over IP using telnet. To
communicate directly with the cellular modem:
1. From Cellular, select Telnet Radio Access.
2. In the pane that appears, check Enabled.
3. To enable raw mode, check Raw. The program transfers data between the computer and cellular modem
without any processing.
4. To enable the Auto Dialout Login feature, check Login. The Auto Dialout port is the Telnet port used by
the redirector software on your computer to communicate to the cellular modem integrated on the
router.
5. In the Port field, type the serial Auto Dialout Port number. The default is 5000.
6. In the Inactivity field, type the time in seconds that the auto dialout session remains active before
becoming inactive.
7. To enable the EIA standard signal characteristics (time and duration) used between different electronic
devices, check Handle EIA Signal.

Radio Status

Field
Module Information
IMEI
MEID
IMSI
Manufacturer
Model Number
Hardware Revision
MDN (Phone Number)
MSID
Firmware Version
Service Information
46
Description
International Mobile Station Equipment Identifier (not available for C2 or EV3
models)
Mobile Equipment Identifier (C2 or EV3 models only)
International Mobile Subscriber Identifier
Company that developed the cellular module
Manufacturer model ID
Module's hardware revision
Mobile Directory Number
Mobile Station ID
Module's firmware version
Description
String used to acknowledge (to the delivering SMSC) the
receipt of an SMS.
Router initialization strings specific to the integrated
cellular modem required for the Wake Up On Call
feature.
MultiConnect
®
rCell 100 MTR-H5 User Guide
