CHAPTER 1 PRODUCT OVERVIEW
Category
WiFi
SIM Holder
GPS
Power Requirements
Voltage
Physical Description
Dimensions
Weight
Environment
Operating Temperature
Humidity
Certifications, Compliance, Warranty
EMC Compliance
Safety Compliance
Network Compliance
Warranty
1
Optional power supply must be a Listed ITE power supply marked LPS or Class 2 rated 7-32Vdc, 1A minimum.
Certification does not apply or extend to Voltages outside certified range, and has not been evaluated by UL for
operating voltages beyond tested range.
2
UL Recognized @ 40° C, Limited by AC power supply. UL Recognized @ 60° C when used with the fused DC power
cable, part number FPC-532-DC.
Installation in outdoor locations has not been evaluated by UL. UL Certification does not apply or extend to use
outdoor applications.
Note: Radio performance may be affected at the temperature extremes. This is considered normal. There is no
single cause for this function. Rather, it is the result of an interaction of several factors, such as the ambient
temperature, the operating mode and the transmit power.
12
Description
Reverse polarity male SMA connector for Wi-Fi
Mini-SIM, standard 1.8 V and 3 V SIM receptacle
Female SMA connector
1
7 V to 32 V DC
Refer to the Dimensions topic that follows.
8.2 ounces or 230 grams
2
-40° C to +85° C
Relative humidity 15% to 93% non-condensing
EN55022 Class B
EN55024
UL 60950-1
UL 201
IEC 60950-1
ANSI/ISA 12.12.01 2013 and CSA C22.2 No. 213
EN 60079-0:2012+A11:2013
EN 60079-15:2010
GCF
Two years
®
MultiConnect rCell 100 MTR-H5 User Guide
